Parameter Descriptions
The function is activated when one of the following
options is selected: either [10] Danfoss OGD LA10 or [11]
Danfoss OGD V206 in parameter 1-11 Motor Model.
The frequency converter checks if the correct OGD model
is selected. If a wrong OGD model is selected, the
frequency converter performs the following actions:
•
Trips
•
Issues an alarm
•
Sets the parameters defined for the correct model
type
•
Waits for the Reset signal from the operator
The model check takes place every time the frequency
converter gets a start signal from the LCP, a digital input
or a fieldbus.
1-14 Damping Gain
Range: Function:
140 [0 - The damping gain stabilises the PM machine to
% 250 %] run smoothly and with stability. The value of
*
damping gain controls the dynamic performance
of the PM machine. High damping gain gives
high dynamic performance and low damping
gain gives low dynamic performance. The
dynamic performance is related to the machine
data and load type. If the damping gain is too
high or low, the control becomes unstable.
1-15 Low Speed Filter Time Const.
Range: Function:
Size related [0.01 - 20 This time constant is used below 10%
*
s] rated speed. Obtain quick control
through a short damping time
constant. However, if this value is too
short, the control becomes unstable.
1-16 High Speed Filter Time Const.
Range: Function:
Size related [0.01 - 20 This time constant is used above 10%
*
s] rated speed. Obtain quick control
through a short damping time
constant. However, if this value is too
short, the control becomes unstable.
1-17 Voltage filter time const.
Range: Function:
Size [0.001 - 1 Reduces the influence of high
related s] frequency ripple and system
*
resonance in the calculation of supply
voltage. Without this filter, the ripples
in the currents can distort the
calculated voltage and affect the
stability of the system.
MG33MJ02
Programming Guide
1-18 Min. Current at No Load
Range:
0 %
*
3.3.6 1-2* Motor Data
This parameter group contains input data from the
nameplate on the connected motor.
NOTICE
Changing the value of these parameters affects the
setting of other parameters.
NOTICE
1-20 Motor Power [kW], 1-21 Motor Power [HP], 1-22 Motor
Voltage, and 1-23 Motor Frequency have no effect when
1-10 Motor Construction is set to [1] PM, non-salient SPM,
[2] PM, salient IPM, [5] Sync. Reluctance.
1-20 Motor Power [kW]
Range:
Size
related
*
1-21 Motor Power [HP]
Range:
Size
related
*
1-22 Motor Voltage
Range:
Size
related
*
Danfoss A/S © Rev. 10/2014 All rights reserved.
Function:
[0 - 50 %] Adjust this parameter to achieve a smoother
motor operation.
Function:
NOTICE
[ 0.09 -
3000.00
This parameter cannot be adjusted
kW]
while the motor is running.
Enter the nominal motor power in kW
according to the motor nameplate data.
The default value corresponds to the
nominal rated output of the frequency
converter.
This parameter is visible in the LCP if
parameter 0-03 Regional Settings is set to
[0] International.
NOTICE
4 sizes down, 1 size up from
nominal unit rating.
Function:
[ 0.09 - Enter the nominal motor power in hp
3000.00 according to the motor nameplate data.
hp] The default value corresponds to the
nominal rated output of the unit. This
parameter is visible in LCP if
parameter 0-03 Regional Settings is [1] US.
Function:
[ 10 - Enter the nominal motor voltage
1000 V] according to the motor nameplate
