Parameter Descriptions
13-16 RS-FF Operand R
Option:
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] Ok key
[44] Reset key
[45] Left key
[46] Right key
[47] Up key
[48] Down key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[75] Start command given
[76] Digital input x30/2
[77] Digital input x30/3
[78] Digital input x30/4
[79] Digital input x46/1
[80] Digital input x46/3
[81] Digital input x46/5
[82] Digital input x46/7
[83] Digital input x46/9
[84] Digital input x46/11
[85] Digital input x46/13
[90] ATEX ETR cur. warning
[91] ATEX ETR cur. alarm
[92] ATEX ETR freq. warning
[93] ATEX ETR freq. alarm
[94] RS Flipflop 0
[95] RS Flipflop 1
[96] RS Flipflop 2
[97] RS Flipflop 3
[98] RS Flipflop 4
[99] RS Flipflop 5
[100] RS Flipflop 6
[101] RS Flipflop 7
[102] Relay 1
[103] Relay 2
[104] Relay 3
MG33MJ02
Programming Guide
Function:
[OK] is pressed. Only available on
the graphical LCP.
[Reset] is pressed. Only available
on the graphical LCP.
[◄] is pressed. Only available on
the graphical LCP.
[►] is pressed. Only available on
the graphical LCP.
▲
[ ] is pressed. Only available on
the graphical LCP.
▼
[ ] is pressed. Only available on
the graphical LCP.
X47/MCB 113
Danfoss A/S © Rev. 10/2014 All rights reserved.
13-16 RS-FF Operand R
Option:
[105] Relay 4
[106] Relay 5
[107] Relay 6
[108] Relay 7
[109] Relay 8
[110] Relay 9
3.14.4 13-2* Timers
Use the result (TRUE or FALSE) from timers directly to
define an event (see 13-51 SL Controller Event), or as
boolean input in a logic rule (see 13-40 Logic Rule Boolean
1, 13-42 Logic Rule Boolean 2 or 13-44 Logic Rule Boolean 3).
A timer is only FALSE when started by an action (i.e. [29]
Start timer 1) until the timer value entered in this
parameter has elapsed. Then it becomes TRUE again.
All parameters in this parameter group are array
parameters with index 0 to 2. Select index 0 to program
timer 0, select index 1 to program timer 1, and so on.
13-20 SL Controller Timer
Range: Function:
Size [ 0 - Enter the value to define the duration of
related 0] the FALSE output from the programmed
*
timer. A timer is only FALSE if it is started
by an action (i.e. [29] Start timer 1) and until
the given timer value has elapsed.
3.14.5 13-4* Logic Rules
Combine up to 3 boolean inputs (TRUE/FALSE inputs) from
timers, comparators, digital inputs, status bits and events
using the logical operators AND, OR, and NOT. Select
boolean inputs for the calculation in 13-40 Logic Rule
Boolean 1, 13-42 Logic Rule Boolean 2 and 13-44 Logic Rule
Boolean 3. Define the operators used to logically combine
the selected inputs in parameter 13-41 Logic Rule Operator
1 and parameter 13-43 Logic Rule Operator 2.
Par. 13-41
Logic Rule Operator 1
Par. 13-40
Logic Rule Boolean 1
Par. 13-42
Logic Rule Boolean 2
. . .
. . .
Par. 13-44
Logic Rule Boolean 3
Illustration 3.53 Logic Rules
Function:
X47/MCB 113
X47/MCB 113
X47/MCB 113
X34/MCB 105
X34/MCB 105
X34/MCB 105
Par. 13-43
Logic Rule Operator 2
. . .
. . .
