Parameter Descriptions
15-10 Logging Source
Array [4]
Option:
[1651] Pulse Reference
[1652] Feedback[Unit]
[1657] Feedback [RPM]
[1660] Digital Input
[1662] Analog Input 53
[1664] Analog Input 54
[1665] Analog Output 42 [mA]
[1666] Digital Output [bin]
[1675] Analog In X30/11
[1676] Analog In X30/12
[1677] Analog Out X30/8 [mA]
[1689] Configurable Alarm/Warning Word
[1690] Alarm Word
[1692] Warning Word
[1694] Ext. Status Word
[1860] Digital Input 2
[3110] Bypass Status Word
[3470] MCO Alarm Word 1
[3471] MCO Alarm Word 2
15-11 Logging Interval
Array [4]
Range:
Size related [ 0.000 - 0.000 ] Enter the interval in ms between
*
15-12 Trigger Event
Select the trigger event. When the trigger event occurs, a
window is applied to freeze the log. The log then retains a
specified percentage of samples before the occurrence of the
trigger event (parameter 15-14 Samples Before Trigger).
Option:
[0] False
*
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
MG33MJ02
Programming Guide
Function:
Function:
each sampling of the variables to
be logged.
Function:
Danfoss A/S © Rev. 10/2014 All rights reserved.
15-12 Trigger Event
Select the trigger event. When the trigger event occurs, a
window is applied to freeze the log. The log then retains a
specified percentage of samples before the occurrence of the
trigger event (parameter 15-14 Samples Before Trigger).
Option:
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
15-13 Logging Mode
Option: Function:
[0] Log always Select [0] Log always for continuous
*
logging.
[1] Log once on Select [1] Log once on trigger to
trigger conditionally start and stop logging using
15-12 Trigger Event and 15-14 Samples Before
Trigger.
15-14 Samples Before Trigger
Range: Function:
50 [0 - 100] Before a trigger event, enter the percentage of
*
all samples which are to be retained in the log.
See also parameter 15-12 Trigger Event and
parameter 15-13 Logging Mode.
3.16.3 15-2* Historic Log
View up to 50 logged data items via the array parameters
in this parameter group. For all parameters in the group,
[0] is the most recent data, and [49] is the oldest data.
Data is logged every time an event occurs (not to be
confused with SLC events). Events in this context are
defined as a change in one of the following areas:
3 3
