Danfoss VLT AutomationDrive FC 302 Programming Manual page 188

Parameter Lists
4.1.5 1-** Load/Motor
Par. No. # Parameter description
1-0* General Settings
1-00 Configuration Mode
1-01 Motor Control Principle
4 4
1-02 Flux Motor Feedback Source
1-03 Torque Characteristics
1-04 Overload Mode
1-05 Local Mode Configuration
1-06 Clockwise Direction
1-07 Motor Angle Offset Adjust
1-1* Special Settings
1-10 Motor Construction
1-11 Motor Model
1-14 Damping Gain
1-15 Low Speed Filter Time Const.
1-16 High Speed Filter Time Const.
1-17 Voltage filter time const.
1-18 Min. Current at No Load
1-2* Motor Data
1-20 Motor Power [kW]
1-21 Motor Power [hp]
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
1-26 Motor Cont. Rated Torque
Automatic Motor Adaptation
1-29 (AMA)
1-3* Adv. Motor Data
1-30 Stator Resistance (Rs)
1-31 Rotor Resistance (Rr)
1-33 Stator Leakage Reactance (X1)
1-34 Rotor Leakage Reactance (X2)
1-35 Main Reactance (Xh)
1-36 Iron Loss Resistance (Rfe)
1-37 d-axis Inductance (Ld)
1-38 q-axis Inductance (Lq)
1-39 Motor Poles
1-40 Back EMF at 1000 RPM
1-41 Motor Angle Offset
1-44 d-axis Inductance Sat. (LdSat)
1-45 q-axis Inductance Sat. (LqSat)
1-46 Position Detection Gain
1-47 Low Speed Torque Calibration
1-48 Inductance Sat. Point
1-5* Load Indep. Setting
Motor Magnetisation at Zero
1-50 Speed
Min. Speed Normal Magnetising
1-51 [RPM]
186
®
VLT AutomationDrive FC 301/302
Default value
ExpressionLimit
ExpressionLimit
[1] 24 V encoder
[0] Constant torque
[0] High torque
[2] As mode par 1-00
[0] Normal
[0] Manual
[0] Asynchron.
ExpressionLimit
140%
ExpressionLimit
ExpressionLimit
ExpressionLimit
0%
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
[0] Off
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
0 N/A
ExpressionLimit
ExpressionLimit
100%
ExpressionLimit
35%
100%
ExpressionLimit
Danfoss A/S © Rev. 10/2014 All rights reserved.
4-set-up FC 302 Change
only during
operation
All set-ups TRUE
All set-ups FALSE
All set-ups x FALSE
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups FALSE
All set-ups x FALSE
All set-ups FALSE
All set-ups x FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups x FALSE
All set-ups x FALSE
All set-ups FALSE
All set-ups x FALSE
All set-ups FALSE
All set-ups x FALSE
All set-ups x FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups x TRUE
All set-ups TRUE
All set-ups TRUE
Conver- Type
sion index
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
0 Int16
-2 Uint16
-2 Uint16
-3 Uint16
0 Uint16
1 Uint32
-2 Uint32
0 Uint16
0 Uint16
-2 Uint32
67 Uint16
-1 Uint32
- Uint8
-4 Uint32
-4 Uint32
-4 Uint32
-4 Uint32
-4 Uint32
-3 Uint32
-4 Int32
-6 Int32
0 Uint8
0 Uint16
0 Int16
-4 Int32
-4 Int32
0 Uint16
- Uint8
0 Int16
0 Uint16
67 Uint16
MG33MJ02
