Parameter Lists
4.1.8 4-** Limits/Warnings
Par. No. # Parameter description
4-1* Motor Limits
4-10 Motor Speed Direction
4-11 Motor Speed Low Limit [RPM]
4-12 Motor Speed Low Limit [Hz]
4-13 Motor Speed High Limit [RPM]
4-14 Motor Speed High Limit [Hz]
4-16 Torque Limit Motor Mode
4-17 Torque Limit Generator Mode
4-18 Current Limit
4-19 Max. Output Frequency
4-2* Limit Factors
4-20 Torque Limit Factor Source
4-21 Speed Limit Factor Source
4-3* Motor Speed Mon.
4-30 Motor Feedback Loss Function
4-31 Motor Feedback Speed Error
4-32 Motor Feedback Loss Timeout
4-34 Tracking Error Function
4-35 Tracking Error
4-36 Tracking Error Timeout
4-37 Tracking Error Ramping
4-38 Tracking Error Ramping Timeout
Tracking Error After Ramping
4-39 Timeout
4-5* Adj. Warnings
4-50 Warning Current Low
4-51 Warning Current High
4-52 Warning Speed Low
4-53 Warning Speed High
4-54 Warning Reference Low
4-55 Warning Reference High
4-56 Warning Feedback Low
4-57 Warning Feedback High
4-58 Missing Motor Phase Function
4-6* Speed Bypass
4-60 Bypass Speed From [RPM]
4-61 Bypass Speed From [Hz]
4-62 Bypass Speed To [RPM]
4-63 Bypass Speed To [Hz]
MG33MJ02
Programming Guide
Default value 4-set-up
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
100% All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
[0] No function All set-ups
[0] No function All set-ups
[2] Trip All set-ups
300 RPM All set-ups
0.05 s All set-ups
ExpressionLimit All set-ups
10 RPM All set-ups
1 s All set-ups
100 RPM All set-ups
1 s All set-ups
5 s All set-ups
0 A All set-ups
I (P1637)
All set-ups
maxVLT
0 RPM All set-ups
ExpressionLimit All set-ups
-999999.999 N/A All set-ups
999999.999 N/A All set-ups
-999999.999 Reference-
FeedbackUnit All set-ups
999999.999 Reference-
FeedbackUnit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
