Parameter Descriptions
30-04 Wobble Jump Frequency [Hz]
Range:
3 3
30-05 Wobble Jump Frequency [%]
Range:
0 % [0 - 100
*
%]
30-06 Wobble Jump Time
Range:
Size related
*
30-07 Wobble Sequence Time
Range:
10 s [1 - 1000 s] This parameter determines the wobble
*
30-08 Wobble Up/ Down Time
Range:
5 s [0.1 - 1000 s] Defines the individual up and down times
*
30-09 Wobble Random Function
Option:
[0]
*
[1]
30-10 Wobble Ratio
Range:
1 [0.1 - 10] If the ratio 0.1 is selected: t
*
30-11 Wobble Random Ratio Max.
Range:
10 [ par. 17-53 - 10] Enter the maximum allowed wobble
*
170
VLT
Function:
the output frequency is required at the
boundaries of the wobble sequence, the
frequency jump is set in this parameter. If the
traverse system has a very high inertia, a high
jump frequency may create a torque limit
warning or trip (warning/alarm 12) or an
overvoltage warning or trip (warning/alarm 7).
This parameter can only be changed in stop
mode.
Function:
The jump frequency can also be expressed as
percentage of the centre frequency. The
function is the same as for
parameter 30-04 Wobble Jump Frequency [Hz].
[ 0.005 - 5.000 s]
Function:
sequence period. This parameter can only be
changed in stop mode.
Wobble time = t + t
up down
Function:
for each wobble cycle.
Function:
Off
On
Function:
is 10 times
down
greater than t .
up
If the ratio 10 is selected: t is 10 times greater
up
than t .
down
Function:
ratio.
Danfoss A/S © Rev. 10/2014 All rights reserved.
®
AutomationDrive FC 301/302
30-12 Wobble Random Ratio Min.
Range:
0.1 [ 0.1 - par. 30-11] Enter the minimum allowed wobble
*
30-19 Wobble Delta Freq. Scaled
Range:
0 Hz [0 - 1000 Hz] Readout parameter. View the actual
*
3.20.3 30-2* Adv. Start Adjust
30-20 High Starting Torque Time [s]
Range:
Size related
Function:
30-21 High Starting Torque Current [%]
Range:
Size related
30-22 Locked Rotor Protection
This parameter is available for FC 302 only. Available for PM
motors only, in Flux Sensorless mode and VVC
mode.
Option: Function:
[0] Off
[1] On
30-23 Locked Rotor Detection Time [s]
This parameter is available for FC 302 only. Available for PM
motors only, in Flux Sensorless mode and VVC
mode.
Range:
Size related
30-24 Locked Rotor Detection Speed Error [%]
This parameter is available for FC 302 only.
Range:
25 %
*
Function:
ratio.
Function:
wobble delta frequency after scaling has
been applied.
Function:
[0 - 60 s] High starting torque time for PM Motor
*
in Flux mode without feedback. This
parameter is available for FC 302 only.
Function:
[ 0 - 200.0 %] High starting torque current for PM
*
Motor in and Flux mode without
feedback. This parameter is
available for FC 302 only.
Protects the motor from the locked rotor condition. The
control algorithm detects a possible locked rotor
condition in motor and trips the frequency converter to
protect the motor.
Function:
[0.05 - 1 s] Time period for detecting the locked
*
rotor condition. A low parameter
value leads to faster detection.
[0 - 100 %]
plus
open loop
plus
open loop
Function:
