Parameter Descriptions
8-13 Configurable Status Word STW
The status word has 16 bits (0-15). Bits 5 and 12-15 are config-
urable. Each of these bits can be configured to any of the
following options.
Option:
[30] Brake fault (IGBT)
[40] Out of ref range
[41] Load throttle active
[60] Comparator 0
[61] Comparator 1
[62] Comparator 2
[63] Comparator 3
[64] Comparator 4
[65] Comparator 5
[70] Logic Rule 0
[71] Logic Rule 1
[72] Logic Rule 2
[73] Logic Rule 3
[74] Logic Rule 4
[75] Logic Rule 5
[80] SL digital out A
[81] SL digital out B
[82] SL digital out C
[83] SL digital out D
[84] SL digital out E
[85] SL digital out F
[86] ATEX ETR cur. alarm
[87] ATEX ETR freq. alarm
[88] ATEX ETR cur. warning
[89] ATEX ETR freq. warning
[90] Safe Function active
[91] Safe Opt. Reset req.
8-14 Configurable Control Word CTW
Option: Function:
Selection of control word bit 10, if it is active
low or active high.
[0] None
[1] Profile
*
default
[2] CTW Valid,
active low
[3] Safe
Option
Reset
[4] PID error When enabled, it inverts the resulting error
inverse from the process PID controller. Available only
if parameter 1-00 Configuration Mode is set to
[6] Surface Winder, [7] Extended PID Speed OL or
[8] Extended PID Speed CL.
[5] PID reset I When enabled, resets the I-part of the Process
part PID controller. Equivalent to
parameter 7-40 Process PID I-part Reset.
Available only if parameter 1-00 Configuration
MG33MJ02
Programming Guide
Function:
Danfoss A/S © Rev. 10/2014 All rights reserved.
8-14 Configurable Control Word CTW
Option: Function:
Mode is set to [6] Surface Winder, [7] Extended
PID Speed OL or [8] Extended PID Speed CL.
[6] PID enable When enabled, enables the extended process
PID controller. Equivalent to
parameter 7-50 Process PID Extended PID.
Available only if parameter 1-00 Configuration
Mode is set to [6] Surface Winder, [7] Extended
PID Speed OL or [8] Extended PID Speed CL.
8-17 Configurable Alarm and Warningword
The Configurable Alarm and Warning Word has 16 bits (0-15).
Each of those bits can be configured to any of the following
options.
Option:
[0] Off
*
[1] 10 Volts low warning
[2] Live zero warning
[3] No motor warning
[4] Mains phase loss warning
[5] DC link voltage high warning
[6] DC link voltage low warning
[7] DC overvoltage warning
[8] DC undervoltage warning
[9] Inverter overloaded warning
[10] Motor ETR overtemp warning
[11] Motor thermistor overtemp warning
[12] Torque limit warning
[13] Over current warning
[14] Earth fault warning
[17] Controlword timeout warning
[19] Discharge temp high warning
[22] Hoist mech brake warning
[23] Internal fans warning
[24] External fans warning
[25] Brake resistor short circuit warning
[26] Brake powerlimit warning
[27] Brake chopper short circuit warning
[28] Brake check warning
[29] Heatsink temperature warning
[30] Motor phase U warning
[31] Motor phase V warning
[32] Motor phase W warning
[34] Fieldbus communication warning
[36] Mains failure warning
[40] T27 overload warning
[41] T29 overload warning
[45] Earth fault 2 warning
[47] 24V supply low warning
[58] AMA internal fault warning
[59] Current limit warning
[60] External interlock warning
[61] Feedback error warning
