Parameter Descriptions
13-40 Logic Rule Boolean 1
Array [6]
Option:
freq.lim.alarm is active, the output
is 1.
[92] ATEX ETR freq. Selectable, if parameter 1-90 Motor
warning Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
the alarm 163 ATEX ETR
cur.lim.warning is active, the
output is 1.
[93] ATEX ETR freq. alarm Selectable, if parameter 1-90 Motor
Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
the warning 165 ATEX ETR
freq.lim.warning is active, the
output is 1.
[94] RS Flipflop 0 See parameter group13-1*
Comparators.
[95] RS Flipflop 1 See parameter group 13-1*
Comparators.
[96] RS Flipflop 2 See parameter group 13-1*
Comparators.
[97] RS Flipflop 3 See parameter group 13-1*
Comparators.
[98] RS Flipflop 4 See parameter group 13-1*
Comparators.
[99] RS Flipflop 5 See parameter group 13-1*
Comparators.
[100] RS Flipflop 6 See parameter group 13-1*
Comparators
[101] RS Flipflop 7 See parameter group 13-1*
Comparators.
[102] Relay 1
[103] Relay 2
[104] Relay 3 X47/MCB 113
[105] Relay 4 X47/MCB 113
[106] Relay 5 X47/MCB 113
[107] Relay 6 X47/MCB 113
[108] Relay 7 X34/MCB 105
[109] Relay 8 X34/MCB 105
[110] Relay 9 X34/MCB 105
13-41 Logic Rule Operator 1
Array [6]
Option: Function:
Select the first logical operator to use on the
boolean inputs from 13-40 Logic Rule Boolean
1 and 13-42 Logic Rule Boolean 2.
MG33MJ02
Programming Guide
Function:
Danfoss A/S © Rev. 10/2014 All rights reserved.
13-41 Logic Rule Operator 1
Array [6]
Option: Function:
Parameter numbers in square brackets stand
for the boolean inputs of parameters in group
13-** Smart Logic Control.
[0] DISABLED Ignores 13-42 Logic Rule Boolean 2,
parameter 13-43 Logic Rule Operator 2, and
13-44 Logic Rule Boolean 3.
[1] AND Evaluates the expression [13-40] AND [13-42].
[2] OR Evaluates the expression [13-40] OR [13-42].
[3] AND NOT Evaluates the expression [13-40] AND NOT
[13-42].
[4] OR NOT Evaluates the expression [13-40] OR NOT
[13-42].
[5] NOT AND Evaluates the expression NOT [13-40] AND
[13-42].
[6] NOT OR Evaluates the expression NOT [13-40] OR
[13-42].
[7] NOT AND Evaluates the expression NOT [13-40] AND
NOT NOT [13-42].
[8] NOT OR NOT Evaluates the expression NOT [13-40] OR NOT
[13-42].
13-42 Logic Rule Boolean 2
Array [6]
Option: Function:
[0] False Select the second boolean (TRUE
or FALSE) input for the selected
logic rule. See
parameter 13-01 Start Event ([0] -
[61]) and parameter 13-02 Stop
Event ([70] - [75]) for further
description.
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
