Parameter Descriptions
13-44 Logic Rule Boolean 3
Array [6]
Option:
[72] SL Time-out 5
[73] SL Time-out 6
3 3
[74] SL Time-out 7
[75] Start command given
[76] Digital input x30/2
[77] Digital input x30/3
[78] Digital input x30/4
[79] Digital input x46/1
[80] Digital input x46/3
[81] Digital input x46/5
[82] Digital input x46/7
[83] Digital input x46/9
[84] Digital input x46/11
[85] Digital input x46/13
[90] ATEX ETR cur. warning Selectable, if parameter 1-90 Motor
[91] ATEX ETR cur. alarm
[92] ATEX ETR freq.
warning
[93] ATEX ETR freq. alarm
[94] RS Flipflop 0
[95] RS Flipflop 1
[96] RS Flipflop 2
[97] RS Flipflop 3
[98] RS Flipflop 4
[99] RS Flipflop 5
140
®
VLT AutomationDrive FC 301/302
Function:
Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
the alarm 164 ATEX ETR
cur.lim.alarm is active, the output
is 1.
Selectable, if parameter 1-90 Motor
Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
the alarm 166 ATEX ETR
freq.lim.alarm is active, the output
is 1.
Selectable, if parameter 1-90 Motor
Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR. If
the alarm 163 ATEX ETR
cur.lim.warning is active, the
output is 1.
Selectable, if parameter 1-90 Motor
Thermal Protection is set to [20]
ATEX ETR or [21] Advanced ETR]. If
the warning 165 ATEX ETR
freq.lim.warning is active, the
output is 1.
See parameter group 13-1*
Comparators.
See parameter group 13-1*
Comparators.
See parameter group 13-1*
Comparators.
See parameter group 13-1*
Comparators.
See parameter group 13-1*
Comparators.
See parameter group 13-1*
Comparators.
Danfoss A/S © Rev. 10/2014 All rights reserved.
13-44 Logic Rule Boolean 3
Array [6]
Option:
[100] RS Flipflop 6 See parameter group 13-1*
Comparators
[101] RS Flipflop 7 See parameter group 13-1*
Comparators.
[102] Relay 1
[103] Relay 2
[104] Relay 3 X47/MCB 113
[105] Relay 4 X47/MCB 113
[106] Relay 5 X47/MCB 113
[107] Relay 6 X47/MCB 113
[108] Relay 7 X34/MCB 105
[109] Relay 8 X34/MCB 105
[110] Relay 9 X34/MCB 105
3.14.6 13-5* States
13-51 SL Controller Event
Array [20]
Option:
[0] False Select the boolean input (TRUE or
FALSE) to define the Smart Logic
Controller event. See
parameter 13-01 Start Event ([0] -
[61]) and parameter 13-02 Stop
Event ([70] - [74]) for further
description.
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current Limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
Function:
