Danfoss VLT AutomationDrive FC 302 Programming Manual page 198

Parameter Lists
Par. No. # Parameter description
7-56 Process PID Ref. Filter Time
7-57 Process PID Fb. Filter Time
4.1.12 8-** Comm. and Options
4 4
Par. No. # Parameter description
8-0* General Settings
8-01 Control Site
8-02 Control Word Source
8-03 Control Word Timeout Time
8-04 Control Word Timeout Function
8-05 End-of-Timeout Function
8-06 Reset Control Word Timeout
8-07 Diagnosis Trigger
8-08 Readout Filtering
8-1* Ctrl. Word Settings
8-10 Control Word Profile
8-13 Configurable Status Word STW
8-14 Configurable Control Word CTW
8-19 Product Code
8-3* FC Port Settings
8-30 Protocol
8-31 Address
8-32 FC Port Baud Rate
8-33 Parity/Stop bits
8-34 Estimated cycle time
8-35 Minimum Response Delay
8-36 Max. Response Delay
8-37 Max. Inter-Char Delay
8-4* FC MC protocol set
8-40 Telegram Selection
8-41 Parameters for Signals
8-42 PCD Write Configuration
8-43 PCD Read Configuration
8-45 BTM Transaction Command
8-46 BTM Transaction Status
8-47 BTM Timeout
8-48 BTM Maximum Errors
8-49 BTM Error Log
8-5* Digital/Bus
8-50 Coasting Select
8-51 Quick Stop Select
8-52 DC Brake Select
8-53 Start Select
8-54 Reversing Select
8-55 Set-up Select
8-56 Preset Reference Select
8-57 Profidrive OFF2 Select
196
®
VLT AutomationDrive FC 301/302
Default value
0.001 s All set-ups
0.001 s All set-ups
Default value 4-set-up
[0] Digital and ctrl.word All set-ups
ExpressionLimit All set-ups
1 s 1 set-up
ExpressionLimit 1 set-up
[1] Resume set-up 1 set-up
[0] Do not reset All set-ups
[0] Disable 2 set-ups
ExpressionLimit All set-ups
[0] FC profile All set-ups
ExpressionLimit All set-ups
[1] Profile default All set-ups
ExpressionLimit 1 set-up
[0] FC 1 set-up
1 N/A 1 set-up
ExpressionLimit 1 set-up
[0] Even Parity, 1 Stop
bit 1 set-up
0 ms 2 set-ups
10 ms 1 set-up
ExpressionLimit 1 set-up
ExpressionLimit 1 set-up
[1] Standard telegram 1 2 set-ups
0 All set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
[0] Off All set-ups
[0] Off All set-ups
60 s 1 set-up
21 N/A 1 set-up
0.255 N/A All set-ups
[3] Logic OR All set-ups
[3] Logic OR All set-ups
ExpressionLimit All set-ups
[3] Logic OR All set-ups
[3] Logic OR All set-ups
[3] Logic OR All set-ups
[3] Logic OR All set-ups
[3] Logic OR All set-ups
Danfoss A/S © Rev. 10/2014 All rights reserved.
4-set-up FC 302 Change
only during
operation
TRUE
TRUE
FC 302 Change
only during
operation
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
FALSE
TRUE
TRUE
FALSE
TRUE
FALSE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
Conver- Type
sion index
-3 Uint16
-3 Uint16
Conver- Type
sion index
- Uint8
- Uint8
-1 Uint32
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
0 Uint32
- Uint8
0 Uint8
- Uint8
- Uint8
-3 Uint32
-3 Uint16
-3 Uint16
-5 Uint16
- Uint8
- Uint16
0 Uint16
0 Uint16
- Uint8
- Uint8
0 Uint16
0 Uint8
-3 Uint32
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
MG33MJ02
