Parameter Descriptions
[33] Safe stop Indicates that the Safe Torque Off on
activated (FC terminal 37 has been activated.
302 only)
[40] Out of ref Active when the actual speed is outside
range settings in parameter 4-52 Warning Speed
Low to parameter 4-55 Warning Reference
High.
[41] Below Active when actual speed is below speed
reference low reference setting.
[42] Above Active when actual speed is above speed
reference high reference setting.
[43] Extended PID
Limit
[45] Bus Ctrl Controls output via bus. The state of the
output is set in parameter 5-90 Digital &
Relay Bus Control. The output state is
retained in the event of bus time-out.
[46] Bus Ctrl On at Controls output via bus. The state of the
timeout output is set in parameter 5-90 Digital &
Relay Bus Control. In the event of bus
timeout, the output state is set high (On).
[47] Bus Ctrl Off at Controls output via bus. The state of the
timeout output is set in parameter 5-90 Digital &
Relay Bus Control. In the event of bus
timeout, the output state is set low (Off).
[51] MCO-controlled Active when an MCO 302 or MCO 305 is
connected. The output is controlled from
option.
[55] Pulse output
[60] Comparator 0 See parameter group 13-1* Comparators.
If Comparator 0 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[61] Comparator 1 See parameter group 13-1* Comparators.
If Comparator 1 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[62] Comparator 2 See parameter group 13-1* Comparators.
If Comparator 2 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[63] Comparator 3 See parameter group 13-1* Comparators.
If Comparator 3 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[64] Comparator 4 See parameter group 13-1* Comparators.
If Comparator 4 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[65] Comparator 5 See parameter group 13-1* Comparators.
If Comparator 5 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[70] Logic Rule 0 See parameter group 13-4* Logic Rules. If
Logic Rule 0 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[71] Logic Rule 1 See parameter group 13-4* Logic Rules. If
Logic Rule 1 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
[72] Logic Rule 2 See parameter group 13-4* Logic Rules. If
Logic Rule 2 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
MG33MJ02
Programming Guide
[73] Logic Rule 3
[74] Logic Rule 4
[75] Logic Rule 5
[80] SL Digital
Output A
[81] SL Digital
Output B
[82] SL Digital
Output C
[83] SL Digital
Output D
[84] SL Digital
Output E
[85] SL Digital
Output F
[90] kWh counter
pulse
[120] Local referen-ce
active
Danfoss A/S © Rev. 10/2014 All rights reserved.
See parameter group 13-4* Logic Rules. If
Logic Rule 3 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
See parameter group 13-4* Logic Rules. If
Logic Rule 4 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
See parameter group 13-4* Logic Rules. If
Logic Rule 5 is evaluated as TRUE, the
output goes high. Otherwise, it is low.
See parameter 13-52 SL Controller Action.
The output goes high whenever the
Smart Logic Action [38] Set dig. out. A
high is executed. The output goes low
whenever the Smart Logic Action [32] Set
dig. out. A low is executed.
See parameter 13-52 SL Controller Action.
The input goes high whenever the Smart
Logic Action [39] Set dig. out. B high is
executed. The input goes low whenever
the Smart Logic Action [33] Set dig. out. B
low is executed.
See parameter 13-52 SL Controller Action.
The input goes high whenever the Smart
Logic Action [40] Set dig. out. C high is
executed. The input goes low whenever
the Smart Logic Action [34] Set dig. out. C
low is executed.
See parameter 13-52 SL Controller Action.
The input goes high whenever the Smart
Logic Action [41] Set dig. out. D high is
executed. The input goes low whenever
the Smart Logic Action [35] Set dig. out. D
low is executed.
See parameter 13-52 SL Controller Action.
The input goes high whenever the Smart
Logic Action [42] Set dig. out. E high is
executed. The input goes low whenever
the Smart Logic Action [36] Set dig. out. E
low is executed.
See parameter 13-52 SL Controller Action.
The input goes high whenever the Smart
Logic Action [43] Set dig. out. F high is
executed. The input goes low whenever
the Smart Logic Action [37] Set dig. out. F
low is executed.
Sends a pulse (200 ms pulse width) to
output terminal whenever kWh counter
changes (15-02 kWh Counter).
Output is high when 3-13 Reference Site =
[2] Local or when 3-13 Reference Site = [0]
Linked to hand auto at the same time as
the LCP is in Hand On mode.
