Parameter Descriptions
1-33 Stator Leakage Reactance (X1)
Range:
Size [ 0.0400 -
related 400.0000
*
Ohm]
3 3
1-34 Rotor Leakage Reactance (X2)
Range:
Size [ 0.0400 -
related 400.0000
*
Ohm]
44
®
VLT AutomationDrive FC 301/302
Function:
Set the stator leakage reactance of the
motor using one of these methods:
•
Run an AMA on a cold motor.
The frequency converter
measures the value from the
motor.
•
Enter the X value manually.
1
Obtain the value from the
motor supplier.
•
Use the X default setting. The
1
frequency converter establishes
the setting based on the motor
nameplate data.
See Illustration 3.6.
NOTICE
The parameter value is updated
after each torque calibration if
option [3] 1st start with store or
option [4] Every start with store is
selected in parameter 1-47 Torque
Calibration.
NOTICE
This parameter is only relevant for
ASM.
Function:
Set the rotor leakage reactance of the
motor using one of these methods:
•
Run an AMA on a cold motor.
The frequency converter
measures the value from the
motor.
•
Enter the X value manually.
2
Obtain the value from the
motor supplier.
•
Use the X default setting. The
2
frequency converter establishes
the setting based on the motor
nameplate data.
See Illustration 3.6.
Danfoss A/S © Rev. 10/2014 All rights reserved.
1-34 Rotor Leakage Reactance (X2)
Range: Function:
NOTICE
The parameter value is updated
after each torque calibration if
option [3] 1st start with store or
option [4] Every start with store is
selected in parameter 1-47 Torque
Calibration.
NOTICE
This parameter is only relevant for
ASM.
1-35 Main Reactance (Xh)
Range: Function:
Size [ 1.0000 - Set the main reactance of the motor
related 10000.0000 using one of these methods:
*
Ohm]
1.
2.
3.
1-36 Iron Loss Resistance (Rfe)
Range: Function:
Size [ 0 - Enter the equivalent iron loss
related 10000.000 resistance (R
*
Ohm] for iron loss in the motor.
The R
Fe
performing an AMA.
The R
Fe
torque control applications. If R
unknown, leave parameter 1-36 Iron
Loss Resistance (Rfe) on default setting.
1-37 d-axis Inductance (Ld)
Range: Function:
Size [0.0 - Enter line to common direct axis
related 1000.0 inductance of the PM motor. Obtain the
*
mH] value from the permanent magnet motor
data sheet.
If only line-line data are available, divide
the line-line value by 2 to achieve the
line-common (starpoint) value. Alterna-
tively, measure the value with an
inductancemeter. This also takes the
Run an AMA on a cold motor.
The frequency converter
measures the value from the
motor.
Enter the X value manually.
h
Obtain the value from the
motor supplier.
Use the X default setting.
h
The frequency converter
establishes the setting based
on the motor nameplate data.
) value to compensate
Fe
value cannot be found by
value is especially important in
is
Fe
