Parameter Descriptions
Application
Low-inertia applications
I /I <5
Load Motor
3 3
Low-inertia applications
50>I /I >5
Load Motor
High-inertia applications
I /I > 50
Load Motor
High-load at low speed
<30% (rated speed)
Dynamic applications
Table 3.6 Recommendations for Various Applications
If the motor starts oscillating at a certain speed, increase
parameter 1-14 Damping Gain. Increase the damping gain
value in small steps. Depending on the motor, this
parameter can be set to between 10% and 100% higher
than the default value.
1-10 Motor Construction
Option:
[0] Asynchron
*
[1] PM, non
salient SPM
[2] PM, salient
IPM
40
VLT
Settings
Increase 1-17 Voltage filter time const.
by factor 5 to 10.
Reduce 1-14 Damping Gain.
Reduce 1-66 Min. Current at Low
Speed (<100%).
Keep the default values.
Increase 1-14 Damping Gain,
parameter 1-15 Low Speed Filter Time
Const., and parameter 1-16 High
Speed Filter Time Const.
Increase 1-17 Voltage filter time const.
Increase 1-66 Min. Current at Low
Speed to adjust the starting torque.
100% current provides nominal
torque as starting torque. This
parameter is independent of
parameter 30-20 High Starting Torque
Time [s] and parameter 30-21 High
Starting Torque Current [%]). Working
at a current level higher than 100%
for a prolonged time can cause the
motor to overheat.
Increase 14-41 AEO Minimum
Magnetisation for highly dynamic
applications. Adjusting 14-41 AEO
Minimum Magnetisation ensures a
good balance between energy
efficiency and dynamics. Adjust
14-42 Minimum AEO Frequency to
specify the minimum frequency at
which the frequency converter
should use minimum magnetisation.
Function:
Select the motor design type.
Use for asynchronous motors.
Use for salient or non-salient PM motors.
PM motors are divided into 2 groups, with
either surface-mounted (SPM) / non-salient
magnets or interior mounted (IPM) / salient
magnets. This option is valid for FC 302 only.
Use for salient or non-salient PM motors.
PM motors are divided into 2 groups, with
either surface-mounted (SPM) / non-salient
Danfoss A/S © Rev. 10/2014 All rights reserved.
®
AutomationDrive FC 301/302
1-10 Motor Construction
Option:
[5] Sync.
Reluctance
1-11 Motor Model
Option:
[1] Std.
Asynchron
[2] Std. PM, non
salient
[3] Std. PM
salient
[10] Danfoss OGD
LA10
[11] Danfoss OGD
V206
OGD Auto-Detection and Model Change Function
Function:
magnets or interior mounted (IPM) / salient
magnets. This option is valid for FC 302 only.
Use for synchronous reluctance motors. This
option is valid for FC 302 only.
CAUTION
This option has the following firmware
version limitations:
•
Version 7.26 and earlier - do
not use this option. There is a
risk of damage to the frequency
converter.
•
Version 7.27 - use this option
only when flying start is
enabled in
parameter 1-73 Flying Start.
Function:
NOTICE
This parameter is valid for FC 302 and
FCD 302 only.
Automatically sets the manufacturer's values
for the selected motor. If the default value
[1] is used, settings must be determined
manually, according to the
selectionparameter 1-10 Motor Construction.
Default motor model when [0]* Asynchron. is
selected in parameter 1-10 Motor
Construction.
Selectable when [1] PM, non-salient SPM is
selected in parameter 1-10 Motor
Construction.
Selectable when [2] PM, salient IPM is
selected in parameter 1-10 Motor
Construction.
Selectable when [1] PM, non-salient SPM is
selected in parameter 1-10 Motor
Construction. Only available for T4, T5 in 1.5-3
kW. Settings are loaded automatically for this
specific motor.
Selectable when [1] PM, non-salient SPM is
selected in parameter 1-10 Motor
Construction. Only available for T4, T5 in
0.75-3 kW. Settings are loaded automatically
for this specific motor.
