Parameter Descriptions
5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB
113), Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6]
(MCB 105), Relay 8 [7] (MCB 105), Relay 9 [8] (MCB 105))
Option: Function:
[71] Logic rule 1 See parameter group 13-4* Smart
Logic Control. If Logic Rule 1 in SLC is
TRUE, the output goes high.
Otherwise, it is low.
[72] Logic rule 2 See parameter group 13-4* Smart
Logic Control. If Logic Rule 2 in SLC is
TRUE, the output goes high.
Otherwise, it is low.
[73] Logic rule 3 See parameter group 13-4* Smart
Logic Control. If Logic Rule 3 in SLC is
TRUE, the output goes high.
Otherwise, it is low.
[74] Logic rule 4 See parameter group 13-4* Smart
Logic Control. If Logic Rule 4 in SLC is
TRUE, the output goes high.
Otherwise, it is low.
[75] Logic rule 5 See parameter group 13-4* Smart
Logic Control. If Logic Rule 5 in SLC is
TRUE, the output goes high.
Otherwise, it is low.
[80] SL digital output A See parameter 13-52 SL Controller
Action. Output A is low on Smart
Logic Action [32]. Output A is high on
Smart Logic Action [38].
[81] SL digital output B See parameter 13-52 SL Controller
Action. Output B is low on Smart Logic
Action [33]. Output B is high on Smart
Logic Action [39].
[82] SL digital output C See parameter 13-52 SL Controller
Action. Output C is low on Smart
Logic Action [34]. Output C is high on
Smart Logic Action [40].
[83] SL digital output D See parameter 13-52 SL Controller
Action. Output D is low on Smart
Logic Action [35]. Output D is high on
Smart Logic Action [41].
[84] SL digital output E See parameter 13-52 SL Controller
Action. Output E is low on Smart Logic
Action [36]. Output E is high on Smart
Logic Action [42].
[85] SL digital output F See parameter 13-52 SL Controller
Action. Output F is low on Smart Logic
Action [37]. Output F is high on Smart
Logic Action [43].
[120] Local ref active Output is high when
parameter 3-13 Reference Site = [2]
MG33MJ02
Programming Guide
5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB
113), Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6]
(MCB 105), Relay 8 [7] (MCB 105), Relay 9 [8] (MCB 105))
Option:
[121] Remote ref active
[122] No alarm
[123] Start command
activ
[124] Running reverse
[125] Drive in hand
mode
Danfoss A/S © Rev. 10/2014 All rights reserved.
Function:
Local or when
parameter 3-13 Reference Site = [0]
Linked to hand auto at the same time
as the LCP is in Hand On mode.
Reference site Local Remote
set in referen reference
parameter 3-13 ce active
Reference Site active [121]
[120]
Reference site: 1 0
Local
parameter 3-13
Reference Site
[2]
Reference site: 0 1
Remote
parameter 3-13
Reference Site
[1]
Reference site:
Linked to Hand/
Auto
Hand 1 0
Hand ⇒ off
1 0
Auto ⇒ off
0 0
Auto 0 1
Table 3.20 Local Reference Active
Output is high when
parameter 3-13 Reference Site = [1]
Remote or [0] Linked to hand/auto
while the LCP is in Auto On mode.
See above.
Output is high when no alarm is
present.
Output is high when the start
command is high (i.e. via digital input,
bus connection or [Hand On] or [Auto
On]), and a stop has been last
command.
Output is high when the frequency
converter is running counter clockwise
(the logical product of the status bits
'running' AND 'reverse').
Output is high when the frequency
converter is in [Hand on] mode (as
3 3
