Danfoss VLT AutomationDrive FC 302 Programming Manual page 34

Parameter Descriptions
0-31 Min Value of User-defined Readout
Range:
3 3
0-32 Custom Readout Max Value
Range:
100 Custom-
ReadoutUnit
*
0-37 Display Text 1
Range:
0 [0 - Enter a text which can be viewed in the graphical
*
25] display by selecting [37] Display Text 1 in
parameter 0-20 Display Line 1.1 Small, 0-21 Display
Line 1.2 Small, 0-22 Display Line 1.3 Small,
0-23 Display Line 2 Large or 0-24 Display Line 3
Large.
0-38 Display Text 2
Range:
0 [0 - Enter a text which can be viewed in the graphical
*
25] display by selecting [38] Display Text 2 in
parameter 0-20 Display Line 1.1 Small, 0-21 Display
Line 1.2 Small, 0-22 Display Line 1.3 Small,
0-23 Display Line 2 Large or 0-24 Display Line 3
Large.
0-39 Display Text 3
Range:
0 [0 - Enter a text which can be viewed in the graphical
*
25] display by selecting [39] Display Text 3 in
parameter 0-20 Display Line 1.1 Small, 0-21 Display
Line 1.2 Small, 0-22 Display Line 1.3 Small,
0-23 Display Line 2 Large or 0-24 Display Line 3
Large.
3.2.5 0-4* LCP Keypad
Enable, disable and password protect individual keys on
the LCP.
32
Function:
unit in parameter 0-30 Unit for
User-defined Readout. For
quadratic and cubic units the
minimum value is 0.
Function:
[ par. 0-31 - This parameter sets the max.
999999.99 value to be shown when the
CustomRea- speed of the motor has reached
doutUnit] the set value for 4-13 Motor
Speed High Limit [RPM] or
parameter 4-14 Motor Speed High
Limit [Hz] (depends on setting in
parameter 0-02 Motor Speed
Unit).
Function:
Function:
Function:
Danfoss A/S © Rev. 10/2014 All rights reserved.
®
VLT AutomationDrive FC 301/302
0-40 [Hand on] Key on LCP
Option:
[0] Disabled
[1] Enabled
[2] Password
[3] Hand Off/On When [Hand On] is pressed once, the LCP
[4] Hand Off/On
w. Passw.
[9] Enabled, ref
= 0
0-41 [Off] Key on LCP
Option:
[0] Disabled
[1] Enabled
[2] Password Avoids unauthorised stop. If parameter 0-41 [Off]
0-42 [Auto on] Key on LCP
Option:
[0] Disabled
[1] Enabled
[2] Password Avoids unauthorised start in Auto mode. If
0-43 [Reset] Key on LCP
Option:
[0] Disabled
[1] Enabled
[2] Password
[7] Enabled
without OFF
Function:
No effect when [Hand On] is pressed. Select
[0] Disabled to avoid accidental start of the
frequency converter in Hand on mode.
The LCP switches to Hand on mode directly
when [Hand on] is pressed.
After pressing [Hand on] a password is
required. If parameter 0-40 [Hand on] Key on
LCP is included in My Personal Menu, define
the password in parameter 0-65 Quick Menu
Password. Otherwise define the password in
0-60 Main Menu Password.
switches to Off mode. When pressed again,
the LCP switches to Hand on mode.
Same as [3] but a password is required (see
option [2] Password).
Function:
Avoids accidental stop of the frequency converter.
Key on LCP is included in the Quick Menu, then
define the password in parameter 0-65 Quick Menu
Password.
Function:
Avoids accidental start of the frequency converter
in Auto mode.
parameter 0-42 [Auto on] Key on LCP is included in
the Quick Menu, then define the password in
parameter 0-65 Quick Menu Password.
Function:
No effect when [Reset] is pressed. Avoids
accidental alarm reset.
Avoids unauthorised resetting. If
parameter 0-43 [Reset] Key on LCP is included
in the Quick Menu, then define the password
in parameter 0-65 Quick Menu Password.
Resets the frequency converter without setting
it in Off mode.
MG33MJ02
