Parameter Lists
Parameter 1-10 Motor
Construction
Parameter 1-01 Motor Control
Principle
8-** Communications and
options (all parameters)
13-** Smart logic control (all
parameters)
Parameter 14-00 Switching
Pattern
Parameter 14-01 Switching
Frequency
Parameter 14-03 Overmodulation
Parameter 14-04 PWM Random
Parameter 14-06 Dead Time
Compensation
Parameter 14-10 Mains Failure
[0] No function
[1] Ctrl. ramp down
[2] Ctrl. ramp down, trip
[3] Coasting
[4] Kinetic back-up
[5] Kinetic back-up, trip
[6] Alarm
Parameter 14-11 Mains Voltage at
Mains Fault
Parameter 14-12 Function at
Mains Imbalance
Parameter 14-14 Kin. Backup Time
Out
Parameter 14-15 Kin. Backup Trip
Recovery Level
Parameter 14-20 Reset Mode
Parameter 14-21 Automatic
Restart Time
Parameter 14-22 Operation Mode
Parameter 14-24 Trip Delay at
Current Limit
Parameter 14-25 Trip Delay at
Torque Limit
Parameter 14-26 Trip Delay at
Inverter Fault
Parameter 14-29 Service Code
Parameter 14-30 Current Lim Ctrl,
Proportional Gain
Parameter 14-31 Current Lim Ctrl,
Integration Time
Parameter 14-32 Current Lim Ctrl,
Filter Time
Parameter 14-35 Stall Protection
Parameter 14-36 Fieldweakening
Function
Parameter 14-40 VT Level
