Danfoss VLT AutomationDrive FC 302 Programming Manual page 166

Parameter Descriptions
16-86 FC Port REF 1
Range:
0 [-200 -
*
200 ]
3 3
16-87 Bus Readout Alarm/Warning
Range:
0 [0 - 65535] Alarm and warning numbers in hex as displayed
*
16-89 Configurable Alarm/Warning Word
Range:
0 [0 - 65535] This alarm/warning word is configured in
*
3.17.7 16-9* Diagnosis Readouts
NOTICE
When using MCT 10 Set-up Software, the readout
parameters can only be read online, i.e. as the actual
status. This means that the status is not stored in the
MCT 10 Set-up Software file.
16-90 Alarm Word
Range:
0 [0 - 4294967295 ] View the alarm word sent via the serial
*
16-91 Alarm Word 2
Range:
0 [0 - 4294967295] View the alarm word sent via the serial
*
16-92 Warning Word
Range:
0 [0 - 4294967295 ] View the warning word sent via the serial
*
16-93 Warning Word 2
Range:
0 [0 - 4294967295] View the warning word sent via the serial
*
164
VLT
Function:
View the 2-byte status word (STW) sent to the
bus master. Interpretation of the status word
depends on the fieldbus option installed and
the control word profile selected in
8-10 Control Profile.
Function:
in the Alarm log. The high byte contains the
alarm, the low byte the warning. The alarm
number is the first one that occurred after the
last reset.
Function:
parameter parameter 8-17 Configurable Alarm
and Warningword to match the actual
requirements.
Function:
communication port in hex code.
Function:
communication port in hex code.
Function:
communication port in hex code.
Function:
communication port in hex code.
Danfoss A/S © Rev. 10/2014 All rights reserved.
®
AutomationDrive FC 301/302
16-94 Ext. Status Word
Range:
0 [0 - 4294967295] Returns the extended warning word sent
*
Function:
via the serial communication port in hex
code.
MG33MJ02
