Parameter Descriptions
5-19 Terminal 37 Safe Stop
Use this parameter to configure the safe stop functionality. A
warning message makes the frequency converter coast the motor
and enables the automatic restart. An alarm message makes the
frequency converter coast the motor and requires a manual
restart (via a fieldbus, Digital I/O, or by pressing RESET on the
LCP). When the MCB 112 PTC Thermistor Card is mounted, the
PTC options should be configured to get the full benefit from
the alarm handling.
Option: Function:
[8] PTC 1 & Relay This option makes it possible to use
A/W a combination of Alarm and
Warning.
[9] PTC 1 & Relay This option makes it possible to use
W/A a combination of Alarm and
Warning.
NOTICE
Options [4]-[9] are only available when the MCB 112 PTC
Thermistor Card is connected.
NOTICE
When Auto Reset/Warning is selected, the frequency
converter opens up for automatic restart.
Function Num PTC
ber
No Function [0] -
Safe Stop Alarm [1]* -
Safe Stop Warning [3] -
PTC 1 Alarm [4] PTC 1 Safe Stop
[A71]
PTC 1 Warning [5] PTC 1 Safe Stop
[W71]
PTC 1 & Relay A [6] PTC 1 Safe Stop
[A71]
PTC 1 & Relay W [7] PTC 1 Safe Stop
[W71]
PTC 1 & Relay A/W [8] PTC 1 Safe Stop
[A71]
PTC 1 & Relay W/A [9] PTC 1 Safe Stop
[W71]
Table 3.18 Overview of Functions, Alarms and Warnings
W means warning and A means alarm. For further information, see
Alarms and Warnings in the Troubleshooting section in the Design
Guide or the Operating Instructions.
A dangerous failure related to Safe Torque Off issues
Alarm: Dangerous Failure [A72].
Refer to Table 5.1.
MG33MJ02
Programming Guide
5-20 Terminal X46/1 Digital Input
Option:
[0] No operation This parameter is active when option module
*
5-21 Terminal X46/3 Digital Input
Option:
[0] No operation This parameter is active when option module
*
5-22 Terminal X46/5 Digital Input
Option:
[0] No operation This parameter is active when option module
*
5-23 Terminal X46/7 Digital Input
Option:
[0] No operation This parameter is active when option module
*
Relay
5-24 Terminal X46/9 Digital Input
Option:
-
[0] No operation This parameter is active when option module
*
Safe Stop [A68]
Safe Stop [W68]
-
5-25 Terminal X46/11 Digital Input
-
Option:
[0] No operation This parameter is active when option module
*
Safe Stop [A68]
Safe Stop [W68]
5-26 Terminal X46/13 Digital Input
Safe Stop [W68]
Option:
Safe Stop [A68]
[0] No operation This parameter is active when option module
*
Danfoss A/S © Rev. 10/2014 All rights reserved.
Function:
MCB 113 is installed in the frequency
converter. Functions are described under
parameter group 5-1* Digital Inputs.
Function:
MCB 113 is installed in the frequency
converter. Functions are described under
parameter group 5-1* Digital Inputs.
Function:
MCB 113 is installed in the frequency
converter. Functions are described under
parameter group 5-1* Digital Inputs.
Function:
MCB 113 is installed in the frequency
converter. Functions are described under
parameter group 5-1* Digital Inputs.
Function:
MCB 113 is installed in the frequency
converter. Functions are described under
parameter group 5-1* Digital Inputs.
Function:
MCB 113 is installed in the frequency
converter. Functions are described under
parameter group 5-1* Digital Inputs.
Function:
MCB 113 is installed in the frequency
converter. Functions are described under
parameter group 5-1* Digital Inputs.
