Danfoss VLT AutomationDrive FC 302 Programming Manual page 88

Parameter Descriptions
5-10 Terminal 18 Digital Input
Option: Function:
[8] Start Functions are described under parameter group 5-1*
*
Digital Inputs.
5-11 Terminal 19 Digital Input
3 3
Option:
[10] Reversing Functions are described under parameter group
*
5-12 Terminal 27 Digital Input
Option:
[2] Coast inverse Functions are described under parameter
*
5-13 Terminal 29 Digital Input
Option: Function:
Select the function from the available digital input
range and the additional options [60], [61], [63] and
[64]. Counters are used in Smart Logic Control
functions. This parameter is available for FC 302 only.
[14] Jog Functions are described under parameter group 5-1*
*
Digital Inputs.
5-14 Terminal 32 Digital Input
Option:
No operation Functions are described under 5-1* Digital Inputs.
5-15 Terminal 33 Digital Input
Option:
[0] No operation Functions are described under 5-1* Digital
*
5-16 Terminal X30/2 Digital Input
Option:
[0] No operation This parameter is active when option module
*
5-17 Terminal X30/3 Digital Input
Option:
[0] No operation This parameter is active when option module
*
86
VLT
Function:
5-1* Digital Inputs.
Function:
group 5-1* Digital Inputs.
Function:
Select the function from the available digital
input range.
Function:
Select the function from the available digital
input range and the additional options [60],
[61], [63] and [64]. Counters are used in
Smart Logic Control functions.
Inputs.
Function:
MCB 101 is installed in the frequency
converter. Functions are described under
5-1* Digital Inputs.
Function:
MCB 101 is installed in the frequency
converter. Functions are described under
5-1* Digital Inputs.
Danfoss A/S © Rev. 10/2014 All rights reserved.
®
AutomationDrive FC 301/302
5-18 Terminal X30/4 Digital Input
Option:
[0] No operation This parameter is active when option module
*
5-19 Terminal 37 Safe Stop
Use this parameter to configure the safe stop functionality. A
warning message makes the frequency converter coast the motor
and enables the automatic restart. An alarm message makes the
frequency converter coast the motor and requires a manual
restart (via a fieldbus, Digital I/O, or by pressing RESET on the
LCP). When the MCB 112 PTC Thermistor Card is mounted, the
PTC options should be configured to get the full benefit from
the alarm handling.
Option:
[1] Safe Stop Alarm
[3] Safe Stop
Warning
[4] PTC 1 Alarm
[5] PTC 1 Warning
[6] PTC 1 & Relay A
[7] PTC 1 & Relay W This option is used when the PTC
Function:
MCB 101 is installed in the frequency
converter. Functions are described under
5-1* Digital Inputs.
Function:
Coasts frequency converter when
safe stop is activated. Manual reset
from LCP, digital input or fieldbus.
Coasts frequency converter when
safe stop is activated (T-37 off).
When safe stop circuit is reestab-
lished, the frequency converter will
continue without manual reset.
Coasts frequency converter when
Safe Torque Off is activated. Manual
reset from LCP, digital input or
fieldbus.
Coasts frequency converter when
Safe Torque Off is activated (T-37
off). When Safe Torque Off circuit is
reestablished, the frequency
converter continues without manual
reset, unless a Digital input set to
[80] PTC Card 1 is still enabled.
This choice is used when the PTC
option is gated together with a
stop button through a Safety relay
to T-37. Coasts frequency converter
when safe stop is activated. Manual
reset from LCP, digital input or
fieldbus.
option is gated together with a
stop button through a Safety relay
to T-37. Coasts frequency converter
when Safe Torque Off is activated
(T-37 off). When safe stop circuit is
reestablished, the frequency
converter continues without manual
reset, unless a Digital input set to
[80] PTC Card 1 is (still) enabled.
MG33MJ02
