Parameter Descriptions
13-10 Comparator Operand
Array [6]
Option:
[152] SL digital
output C
3 3
[153] SL digital
output D
[154] SL digital
output E
[155] SL digital
output F
[160] Relay 1
[161] Relay 2
[162] Relay 3
[163] Relay 4
[164] Relay 5
[165] Relay 6
[166] Relay 7
[167] Relay 8
[168] Relay 9
[180] Local
referecnce
active
[181] Remote
reference active
[182] Start command
[183] Drive stopped
[185] Drive in hand
mode
[186] Drive in auto
mode
[187] Start command
given
[190] Digital input
x30/2
[191] Digital input
x30/3
[192] Digital input
x30/4
[193] Digital input
x46/1
[194] Digital input
x46/3
[195] Digital input
x46/5
[196] Digital input
x46/7
132
®
VLT AutomationDrive FC 301/302
Function:
Use the result of the SLC output C.
Use the result of the SLC output D.
Use the result of the SLC output E.
Use the result of the SLC output F.
Relay 1 is active
Relay 2 is active
High when parameter 3-13 Reference Site
= [2] Local or when
parameter 3-13 Reference Site is [0] Linked
to hand Auto, at the same time as the
LCP is in Hand On mode.
High when parameter 3-13 Reference Site=
[1] Remote or [0] Linked to hand/auto,
while the LCP is in Auto On mode.
High when there is an active start
command, and no stop command.
A stop command (Jog, Stop, Qstop,
Coast) is issued – and not from the SLC
itself.
High when the frequency converter is in
Hand mode.
High when the frequency converter is in
Auto mode.
Danfoss A/S © Rev. 10/2014 All rights reserved.
13-10 Comparator Operand
Array [6]
Option: Function:
[197] Digital input
x46/9
[198] Digital input
x46/11
[199] Digital input
x46/13
13-11 Comparator Operator
Array [6]
Option: Function:
Select the operator to be used in the
comparison. This is an array parameter
containing comparator operators 0 to 5.
[0] < The result of the evaluation is TRUE, when the
variable selected in parameter 13-10 Comparator
Operand is smaller than the fixed value in
13-12 Comparator Value. The result is FALSE, if
the variable selected in
parameter 13-10 Comparator Operand is greater
than the fixed value in 13-12 Comparator Value.
[1] ≈ (equal) The result of the evaluation is TRUE, when the
variable selected in parameter 13-10 Comparator
Operand is approximately equal to the fixed
value in 13-12 Comparator Value.
[2] > Inverse logic of option < [0].
[5] TRUE
longer
than..
[6] FALSE
longer
than..
[7] TRUE
shorter
than..
[8] FALSE
shorter
than..
13-12 Comparator Value
Array [6]
Range: Function:
Size [-100000 - Enter the 'trigger level' for the
related 100000 ] variable that is monitored by this
*
comparator. This is an array
parameter containing comparator
values 0 to 5.
