Troubleshooting
Num Description
ber
61 Feedback error
62 Output frequency at maximum limit
63 Mechanical brake low
64 Voltage limit
65 Control board overtemperature
66 Heat sink temperature low
67 Option configuration has changed
5 5
68 Safe stop
69 Pwr. card temp
70 Illegal FC configuration
71 PTC 1 Safe Stop
72 Dangerous failure
73 Safe Stop Auto Restart
74 PTC Thermistor
75 Illegal Profile Sel.
76 Power Unit Set-up
77 Reduced power mode
78 Tracking error
79 Illegal PS config
80 Drive Initialised to default value
81 CSIV corrupt
82 CSIV parameter error
83 Illegal option combination
84 No safety option
88 Option detection
89 Mechanical brake sliding
90 Feedback monitor
91 Analog input 54 wrong settings
99 Locked rotor
104 Mixing fans
122 Mot. rotat. unexp.
123 Motor mod. changed
163 ATEX ETR cur.lim.warning
164 ATEX ETR cur.lim.alarm
165 ATEX ETR freq.lim.warning
166 ATEX ETR freq.lim.alarm
220 Configuration File Version not supported
246 Pwr.card supply
250 New spare part
251 New type code
430 PWM Disabled
Table 5.1 Alarm/Warning Code List
(X) Dependent on parameter
1) Cannot be Auto reset via 14-20 Reset Mode
214
®
VLT AutomationDrive FC 301/302
Warning Alarm/Trip
(X) (X)
X
(X)
X
X X
X
X
(X) 1)
(X)
X
X
(X) (X)
X
X
X
(X) (X)
X
X
X
X
X
X
(X) (X)
X
X X
X
X
X
X
X
X
X
X
X
