Parameter Lists
4.1.6 2-** Brakes
Par. No. # Parameter description
2-0* DC-Brake
2-00 DC Hold Current
2-01 DC Brake Current
4 4
2-02 DC Braking Time
2-03 DC Brake Cut In Speed [RPM]
2-04 DC Brake Cut In Speed [Hz]
2-05 Maximum Reference
2-06 Parking Current
2-07 Parking Time
2-1* Brake Energy Funct.
2-10 Brake Function
2-11 Brake Resistor (ohm)
2-12 Brake Power Limit (kW)
2-13 Brake Power Monitoring
2-15 Brake Check
2-16 AC brake Max. Current
2-17 Over voltage Control
2-18 Brake Check Condition
2-19 Over voltage Gain
2-2* Mechanical Brake
2-20 Release Brake Current
2-21 Activate Brake Speed [RPM]
2-22 Activate Brake Speed [Hz]
2-23 Activate Brake Delay
2-24 Stop Delay
2-25 Brake Release Time
2-26 Torque Ref
2-27 Torque Ramp Up Time
2-28 Gain Boost Factor
2-29 Torque Ramp Down Time
2-3* Adv. Mech Brake
2-30 Position P Start Proportional Gain
2-31 Speed PID Start Proportional Gain
2-32 Speed PID Start Integral Time
Speed PID Start Low-pass Filter
2-33 Time
188
®
VLT AutomationDrive FC 301/302
Default value
50%
50%
10 s
ExpressionLimit
ExpressionLimit
MaxReference (P303)
50%
3 s
ExpressionLimit
ExpressionLimit
ExpressionLimit
[0] Off
[0] Off
100%
[0] Disabled
[0] At Power-up
100%
I (P1637)
maxVLT
ExpressionLimit
ExpressionLimit
0 s
0 s
0.20 s
0%
0.2 s
1 N/A
0 s
0.0000 N/A
0.0150 N/A
200.0 ms
10.0 ms
Danfoss A/S © Rev. 10/2014 All rights reserved.
4-set-up FC 302 Change
only during
operation
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
Conver- Type
sion index
0 Uint8
0 Uint16
-1 Uint16
67 Uint16
-1 Uint16
-3 Int32
0 Uint16
-1 Uint16
- Uint8
0 Uint16
0 Uint32
- Uint8
- Uint8
-1 Uint32
- Uint8
- Uint8
0 Uint16
-2 Uint32
67 Uint16
-1 Uint16
-1 Uint8
-1 Uint8
-2 Uint16
-2 Int16
-1 Uint8
-2 Uint16
-1 Uint8
-4 Uint32
-4 Uint32
-4 Uint32
-4 Uint16
