Parameter Descriptions
0-20 Display Line 1.1 Small
Option:
[1609] Custom Readout
[1610] Power [kW]
3 3
[1611] Power [hp]
[1612] Motor Voltage
[1613] Frequency
[1614] Motor current
[1615] Frequency [%]
[1616] Torque [Nm]
[1617] Speed [RPM]
*
[1618] Motor Thermal
[1619] KTY sensor
temperature
[1620] Motor Angle
[1621] Torque [%] High
Res.
[1622] Torque [%]
[1623] Motor Shaft Power
[kW]
[1624] Calibrated Stator
Resistance
[1625] Torque [Nm] High
[1630] DC Link Voltage
[1632] Brake Energy /s
[1633] Brake Energy
Average
[1634] Heatsink Temp.
[1635] Inverter Thermal
28
®
VLT AutomationDrive FC 301/302
Function:
Actual power consumed by the
motor in kW.
Actual power consumed by the
motor in hp.
Voltage supplied to the motor.
Motor frequency, i.e. the output
frequency from the frequency
converter in Hz.
Phase current of the motor
measured as effective value.
Motor frequency, i.e. the output
frequency from the frequency
converter in percent.
Actual motor torque in Nm
Speed in RPM (revolutions per
minute), i.e. the motor shaft speed
in closed loop.
Thermal load on the motor,
calculated by the ETR function.
Present motor load as a
percentage of the rated motor
torque.
Intermediate circuit voltage in the
frequency converter.
Present brake power transferred to
an external brake resistor.
Stated as an instantaneous value.
Brake power transferred to an
external brake resistor. The mean
power is calculated continuously
for the most recent 120 s.
Present heat sink temperature of
the frequency converter. The cut-
out limit is 95 ±5 °C; cutting back
in occurs at 70 ±5 °C.
Percentage load of the inverters.
Danfoss A/S © Rev. 10/2014 All rights reserved.
0-20 Display Line 1.1 Small
Option: Function:
[1636] Inv. Nom. Current Nominal current of the frequency
converter.
[1637] Inv. Max. Current Maximum current of the frequency
converter.
[1638] SL Controller State State of the event executed by the
control.
[1639] Control Card Temp. Temperature of the control card.
[1645] Motor Phase U
Current
[1646] Motor Phase V
Current
[1647] Motor Phase W
Current
[1648] Speed Ref. After
Ramp [RPM]
[1650] External Reference Sum of the external reference as a
percentage, i.e. the sum of analog/
pulse/bus.
[1651] Pulse Reference Frequency in Hz connected to the
digital inputs (18, 19 or 32, 33).
[1652] Feedback[Unit] Reference value from programmed
digital input(s).
[1653] Digi Pot Reference
[1657] Feedback [RPM]
[1660] Digital Input Signal states from the 6 digital
terminals (18, 19, 27, 29, 32 and
33). There are 16 bits in total, but
only 6 of them are used. Input 18
corresponds to the far left of the
used bits. Signal low = 0; Signal
high = 1.
[1661] Terminal 53 Switch Setting of input terminal 54.
Setting Current = 0; Voltage = 1.
[1662] Analog Input 53 Actual value at input 53 either as a
reference or protection value.
[1663] Terminal 54 Switch Setting of input terminal 54.
Setting Current = 0; Voltage = 1.
[1664] Analog Input 54 Actual value at input 54 either as
reference or protection value.
[1665] Analog Output 42 Actual value at output 42 in mA.
[mA] Use parameter 6-50 Terminal 42
Output to select the value to be
shown.
[1666] Digital Output [bin] Binary value of all digital outputs.
[1667] Freq. Input #29 [Hz] Actual value of the frequency
applied at terminal 29 as an
impulse input.
