Parameter Descriptions
13-51 SL Controller Event
Array [20]
Option:
[106] Relay 5
3 3
[107] Relay 6
[108] Relay 7
[109] Relay 8
[110] Relay 9
13-52 SL Controller Action
Array [20]
Option:
[0] DISABLED
[1] No action
[2] Select set-up 1 Changes the active set-up
[3] Select set-up 2 Changes the active set-up
[4] Select set-up 3 Changes the active set-up
[5] Select set-up 4 Changes the active set-up
[10] Select preset
ref 0
[11] Select preset
ref 1
[12] Select preset
ref 2
142
®
VLT AutomationDrive FC 301/302
Function:
X47/MCB 113
X47/MCB 113
X34/MCB 105
X34/MCB 105
X34/MCB 105
Function:
Select the action corresponding to the SLC
event. Actions are executed when the
corresponding event (defined in
parameter 13-51 SL Controller Event) is
evaluated as true. The following actions are
available for selection:
[0] *DISABLED
(parameter 0-10 Active Set-up) to '1'.
If the set-up is changed, it merges with
other set-up commands coming from either
the digital inputs or via a fieldbus.
parameter 0-10 Active Set-up) to '2'.
If the set-up is changed, it merges with
other set-up commands coming from either
the digital inputs or via a fieldbus.
(parameter 0-10 Active Set-up) to '3'.
If the set-up is changed, it merges with
other set-up commands coming from either
the digital inputs or via a fieldbus.
(parameter 0-10 Active Set-up) to '4'.
If the set-up is changed, it merges with
other set-up commands coming from either
the digital inputs or via a fieldbus.
Selects preset reference 0.
If the active preset reference is changed, it
merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
Selects preset reference 1.
If the active preset reference is changed, it
merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
Selects preset reference 2.
Danfoss A/S © Rev. 10/2014 All rights reserved.
13-52 SL Controller Action
Array [20]
Option: Function:
If the active preset reference is changed, it
merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
[13] Select preset Selects preset reference 3.
ref 3 If the active preset reference is changed, it
merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
[14] Select preset Selects preset reference 4.
ref 4 If the active preset reference is changed, it
merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
[15] Select preset Selects preset reference 5.
ref 5 If the active preset reference is changed, it
merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
[16] Select preset Selects preset reference 6.
ref 6 If the active preset reference is changed, it
merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
[17] Select preset Selects preset reference 7.
ref 7 If the active preset reference is changed, it
merges with other preset reference
commands coming from either the digital
inputs or via a fieldbus.
[18] Select ramp 1 Selects ramp 1.
[19] Select ramp 2 Selects ramp 2.
[20] Select ramp 3 Selects ramp 3.
[21] Select ramp 4 Selects ramp 4.
[22] Run Issues a start command to the frequency
converter.
[23] Run reverse Issues a start reverse command to the
frequency converter.
[24] Stop Issues a stop command to the frequency
converter.
[25] Qstop Issues a quick stop command to the
frequency converter.
[26] Dcstop Issues a DC stop command to the
frequency converter.
[27] Coast The frequency converter coasts
immediately. All stop commands including
the coast command stop the SLC.
