Parameter Descriptions
6-46 Term. X30/12 Filter Time Constant
Range: Function:
NOTICE
0.001 s [0.001 - 10
*
s]
This parameter cannot be adjusted
while the motor is running.
Enter the filter time constant. This
constant is a first-order digital low-pass
filter time for suppressing electrical noise
in terminal X30/12. A high value improves
dampening, but also increases the delay
through the filter.
3.8.6 6-5* Analog Output 1
Parameters for configuring the scaling and limits for
analog output 1, i.e. terminal 42. Analog outputs are
current outputs: 0/4 to 20 mA. Common terminal (terminal
39) is the same terminal and has the same electrical
potential for analog common and digital common
connection. Resolution on analog output is 12 bit.
6-50 Terminal 42 Output
Option: Function:
Select the function of Terminal 42 as an
analog current output. Depending on the
selection the output is either a 0-20mA or
4-20mA output. The current value can be
read out in in parameter 16-65 Analog Output
42 [mA].
[0] No When no signal on the analog output.
operation
[52] MCO
0-20mA
[53] MCO
4-20mA
[100] Output 0Hz = 0mA; 100Hz = 20mA.
frequency
[101] Reference Parameter 3-00 Reference Range [Min - Max]
0% = 0mA; 100% = 20mA
Parameter 3-00 Reference Range [-Max - Max]
-100% = 0mA; 0% = 10mA; +100% = 20mA
[102] Feedback
[103] Motor Value is taken from parameter 16-37 Inv. Max.
Current Current. Inverter max. current (160% current)
is equal to 20mA.
Example: Inverter norm current (11kW) =
24A. 160% = 38.4A. Motor norm current =
22A Read-out 11.46mA.
mA x 22 A
20
A
38.4
In case the norm motor current is equal to
20mA, the output setting of
MG33MJ02
Programming Guide
= 11.46 mA
Danfoss A/S © Rev. 10/2014 All rights reserved.
6-50 Terminal 42 Output
Option: Function:
parameter 6-52 Terminal 42 Output Max Scale
is:
IVLT Max x 100
IMotor Norm
[104] Torque rel The torque setting is related to setting in
to limit parameter 4-16 Torque Limit Motor Mode
[105] Torq relate The torque is related to the motor torque
to rated setting.
[106] Power Taken from parameter 1-20 Motor Power [kW].
[107] Speed Taken from parameter 3-03 Maximum
Reference. 20mA = value in
parameter 3-03 Maximum Reference
[108] Torque Torque reference related to 160% torque.
[109] Max Out 0Hz = 0mA,parameter 4-19 Max Output
Freq Frequency = 20mA.
[113] PID
Clamped
Output
[119] Torque %
lim
[130] Output 0Hz = 4mA, 100Hz = 20mA
freq.
4-20mA
[131] Reference Parameter 3-00 Reference Range [Min-Max] 0%
4-20mA = 4mA; 100% = 20mA
Parameter 3-00 Reference Range [-Max-Max]
-100% = 4mA; 0% = 12mA; +100% = 20mA
[132] Feedback
4-20mA
Value is taken from parameter 16-37 Inv. Max.
[133] Motor cur.
4-20mA Current. Inverter max. current (160% current)
is equal to 20mA.
Example: Inverter norm current (11kW) =
24A. 160% = 38.4A. Motor norm current =
22A Read-out 11.46mA.
mA x 22 A
16
A
38.4
In case the norm motor current is equal to
20mA, the output setting of
parameter 6-62 Terminal X30/8 Max. Scale is:
IVLT Max x 100
IMotor Norm
[134] Torq.% lim The torque setting is related to setting in
4-20 mA parameter 4-16 Torque Limit Motor Mode.
[135] Torq.% The torque setting is related to the motor
nom torque setting.
4-20mA
[136] Power Taken from parameter 1-20 Motor Power [kW]
4-20mA
38.4 x 100
= = 175%
22
mA = 13.17 mA
+ 4
x 100
38.4
= = 175%
22
