Epson S5U1C17001C Manual page 665

11 OTHEr TOOlS
User's Name
Enter your company name. You can enter up to 40 characters. You can use English letters, numbers, symbols,
and spaces. The content entered here is recorded in the USER'S NAME field of the function option document
file.
Comment
Enter a comment. Up to 50 characters can be entered in one line. You can enter up to 10 lines. You can use
English letters, numbers, symbols, and spaces. Use the [Enter] key to create a new line. All comments should
include the following information:
• Place of business, your department or section
• Address, telephone number, and facsimile number
• Other: Technical information, etc.
The content entered here is recorded in the COMMENT field of the function option document file.
When you have finished entering the above necessary items, click [OK]. The setup contents are saved, and the
dialog box is closed. The setup contents take effect immediately. If you click [Cancel], current settings will not
be changed and the dialog box is closed.
notes: • File name specification is subject to the following limitations:
1. The number of characters that can be used to specify a file name including the path is 2,048.
2. The file name itself (not including the extension) can be up to 15 characters, and the
extension up to three characters.
3. The file name cannot begin with a hyphen (-), nor can the following symbols be used as
part of directory names (folder names), file names, and extensions:
/ : , ; * ? " < > |
• The symbols shown below cannot be used in the User's Name and Comment:
$ \ | `
(3) Selecting options
Select necessary options by clicking the corresponding check boxes in the option list. When you change any
selection item in the option list area, the display in the function option document area is updated. Note that
when you have loaded the device information definition file, the option list is placed in its default selection
state.
For details about option specifications, refer to the Technical Manual available for each type of microcomputer.
(4) Creating files
After selecting options, select [Generate] from the [Tool] menu or click the [Generate] button to create the files.
[Generate] button
The function option document file you specified from the [Setup] dialog box is created. When winfog17 has
finished creating the files normally, it displays the message "Making file(s) is completed" in the message area.
If an error occurs, an error message is displayed.
11-38
EPSOn
(C COMPilEr PaCkagE fOr S1C17 faMily) (Ver. 1.5.0)
S5U1C17001C ManUal
