artifacts.xml
\configuration
\dropins
\features
\jre
\p2
\plugins
\readme
\essim17
\utility
\tool
\dev
\sample
\mcu_model
\doc
Refer to the "readmeVxx.txt" for the contents of the "sample" and "utility" directories.
Precaution when installing over existing version
If the gnu17 tools have been installed over the old version, changes in the GNU17 IDE may not be reflected in
the new version just installed. If this happens, temporarily close GNU17 IDE, then start from the command line
prompt, as described below.
C:\EPSON\gnu17\eclipse>eclipse.exe -clean
Precautions on setting the OS
• Select to "regular" font size in "Display Properties".
• When using a drive on the network as the tool and/or work drive, be sure to assign a drive name to it. The
network name cannot be used.
• Do not use the USB port for the ICD in other drivers and applications. Furthermore, make sure that the port has
been enabled when using a note PC as some can disable USB port.
• If the gdb debugger or GNU17 IDE have a problem on the GUI that causes an abnormal display, decrease
the function level of the graphics or use a low-level standard display driver which has been supplied in the
Windows package.
Uninstalling the tools
To uninstall the tools, select [UnInstall] from [EPSON MCU] > [GNU17] in Windows startup menu, then click
the [OK] button in the subsequent dialog box.
You also can use Add/Remove Programs in the Control Panel to uninstall the tools.
note: If you set the \EPSON\gnu17\eclipse\workspace directory in the workspace, make a backup of
the workspace directory before removing the tools. (Projects are saved to this directory.)
S5U1C17001C ManUal
(C COMPilEr PaCkagE fOr S1C17 faMily) (Ver. 1.5.0)
: Eclipse update manager file
: Startup configuration file and other files
: plug-in folder (empty folder)
: Features
: Java virtual machine
: Eclipse update manager folder
: Plug-in
: Release note
: Embedded system simulator
: Utility
: Middleware and other tools
: ROM data production tool
: Sample file
: Model-specific information tool
: Manual and other documents
EPSOn
2 inSTallaTiOn
2
Install
2-5
