Temporary Breakpoint: Symbols indicating temporary software PC breakpoints
Hardware Breakpoint: Symbols indicating hardware PC breakpoints
Variable Balloons
Turn on or off the function to display symbol values in a balloon. By default, this function is turned on.
Tab Size
Specifies the width of tab stops used in source display by using a number of characters. By default, the tab
size is set to 4 characters.
[apply] button
Changes the settings made in the dialog box without closing with the dialog box.
[Ok] button
Changes settings made in the dialog box and closes the dialog box.
[Cancel] button
Closes the dialog box without changing the settings you made there. (Note that settings already changed by
[Apply] cannot be undone.)
Clicking [Apply] or closing this dialog box updates the contents displayed in the [Source] and other windows.
Command execution from menus or toolbar buttons
The following commands can be executed from menus or toolbar buttons:
c17 rst command:
step command:
stepi command:
next command:
nexti command:
finish command:
continue command:
User defined command:
*1 The [Reset] command in the [Reset] menu and the [Reset] button execute the command file \gnu17\reset.gdb (the
c17 rst command only is included at shipment).
*2 The [User command] command in the [User] menu and the [User Command] button execute the command file \gnu17\
userdefine.gdb (no executable command is included at shipment).
*3 The step, stepi, next and nexti commands are executed for only one step from the current PC address.
*4 The continue command is executed continuously, without specifying the number of invalid breaks.
limitations
• The contents displayed in the [Source] window cannot be edited from the keyboard, by copying text, or using
any other means.
• The contents displayed in the [Source] window do not change even when a command is used to correct the
contents of memory in the program area.
S5U1C17001C ManUal
(C COMPilEr PaCkagE fOr S1C17 faMily) (Ver. 1.5.0)
(by default, R = 255, G = 165, and B = 0)
(by default, R = 0, G = 0, and B = 255)
[Reset] on [Reset] menu, [Reset] button
[Step] on [Control] menu, [Step] button
[Step Asm Inst] on [Control] menu, [Step Asm Inst] button
[Next] on [Control] menu, [Next] button
[Next Asm Inst] on [Control] menu, [Next Asm Inst] button
[Finish] on [Control] menu, [Finish] button
[Continue] on [Control] menu, [Continue] button
[User command] on [User] menu, [User Command] button
EPSOn
*1
*3
*3
*3
*3
*4
*2
