11.9.4 Window

Option list area
Message area
* The microcomputer model name on the title bar is the file name (not including the path and extension) of the device
information definition file that has been read.
* The option list and the function option document vary with each type of microcomputer.
The [FOG] window is divided into three areas as shown above.
Option list area
Lists mask options set in the device information definition file (S1C17xxx.ini). Use the check boxes in this area
to select each option. A selected option has its check box marked by ✓.
function option document area
Displays the contents of selected options in the function option document format. The contents displayed in this
area are output to the function option document file. When you change any selected item in the option list area,
the display in this area is immediately updated.
Message area
When you create a file by selecting [Generate] from the [Tool] menu or clicking the [Generate] button, this area
displays a message showing the result of the selected operation.
S5U1C17001C ManUal
(C COMPilEr PaCkagE fOr S1C17 faMily) (Ver. 1.5.0)
← →
↑
↓
The area can be resized by dragging the frame boundary.
Figure 11.9.4.1 Window configuration
