Operation
Opening and closing the window
The [Source] window opens automatically at debugger startup.
If necessary, multiple instances of the [Source] window can be opened to display two or more source files
simultaneously. To open another [Source] window, right-click somewhere in the current [Source] window and
choose [Open Another Source Window] from the ensuing popup menu.
At least one [Source] window must remain open. When all [Source] windows are closed, the debugger enters
shutdown processing. The windows can be minimized, however.
The [Source] window also has a function to open other windows. Choose the window you wish to open from
the [View] menu or click the corresponding toolbar button. See the menus and toolbar buttons described above.
Changing display format
Any display format can be selected from the pull-down list as explained earlier. When you select a different
display format, the contents displayed in the window change immediately. However, you cannot change
the display format of a source file whose current PC or browse (function/label search) is not highlighted to
[ASSEMBLY].
Selecting between source files
Select the source file name you wish to display from the list in the source file select combo box or enter the
source file name from the keyboard.
function/label browse
Enter a function name or assembly source label in the function/label browse combo box to update the contents
displayed in the window to the specified position. Moreover, the line of instruction on the first source line or at
the label position to be executed in that function is highlighted (by default, in cyan).
The background color of this highlighting can be changed in the [Source Preferences] dialog box that appears
when [Source...] is selected from the [Preferences] menu.
Because the function or label names defined in the source file displayed are also listed in the combo box, you
can choose one from the list and jump to that position.
This browse and highlighting does not affect the PC address or program execution.
S5U1C17001C ManUal
(C COMPilEr PaCkagE fOr S1C17 faMily) (Ver. 1.5.0)
EPSOn
10 DEBUggEr
10
Debugger
10-15
