5.3.14 View Manipulation

This section describes how to open or close any view of the IDE and how to change the layout of a view.
Opening/closing a view
The displayed view is closed by clicking the
pane itself goes out.
To open a closed view, select it from [Show View] on the [Window] menu. The pane in which a selected view is
displayed depends on how the perspective (described later) is set.
If multiple views overlap one on top of another in one pane, use the tab at the top of each view to select the
view you want to display.
Changing the view layout
You can change the position at which a view is displayed by dragging its tab. When you drag the tab of a view
to a relocatable position, a rectangular frame is displayed indicating the destination to which the view will be
moved. For example, when you drag the tab of a view to a position in another pane and a frame in size of that
pane and directory icons are displayed, the view is moved to that pane. Even when a frame in size of the tab is
displayed at the tab position, the view is moved to that pane, in which case you can select a position in the stack
of tabs at which you want to insert. If an arrow icon and a different size frame appears when you dragged a
view's tab, the pane will be separated and the view will be displayed in a new pane.
The size of any pane can also be changed by dragging the boundary border of the pane.
Maximizing a view
When you double-click the tab of a view, a pane including the selected view is expanded to the size of the IDE
window, with other views hidden behind it. When you double-click the tab of a maximized view, the view re-
verts to its original size. Each pane has a maximize button at the upper right corner. Click this button to maxi-
mize a view. A minimize button restores the view to its original size. If you click the minimize button of a view
in ordinary display, only the tab is displayed.
Maximize button
Minimize button
