- Page 1 MF1434 - 01 CMOS 8 - BIT SINGLE CHIP MICROCOMPUTER S5U1C88000P Manual (S1C88 Family Peripheral Circuit Board)
- Page 2 No part of this material may be reproduced or duplicated in any form or by any means without the written permission of Seiko Epson. Seiko Epson reserves the right to make changes to this material without notice. Seiko Epson does not assume any...
- Page 3 New configuration of product number Starting April 1, 2001, the product number has been changed as listed below. Please use the new product number when you place an order. For further information, please contact Epson sales representative. Devices 88104 0A01...
-
Page 5: Table Of Contents
CONTENTS S5U1C88000P Manual (S1C88 Family Peripheral Circuit Board) This manual describes how to use the S1C88 Family Peripheral Circuit Board (S5U1C88000P). This circuit board is used to provide emulation functions when it is installed in the ICE (S5U1C88000H5), a debug- ging tool for the 8-bit Single Chip Microcomputer S1C88 Family. -
Page 7: Chapter 1 Introduction
NTRODUCTION 1.1 Outline of S5U1C88000P The S5U1C88000P provides on a board all the peripheral circuits of S1C88 Family microcomputers other than the core CPU. By installing this board in the ICE (S5U1C88000H5) you can use it to emulate each model in the S1C88 Family. This board contains a programmable gate array (FPGA) and supports each model by downloading the circuit data from the host PC to the FPGA via the ICE. -
Page 8: Chapter 2 Setting U P The S5U1C88000P
ETTING P THE 2.1 Installing the S5U1C88000P in the ICE (S5U1C88000H5) Insert this board along by the lower guide rail of the ICE (S5U1C88000H5). The system may fail to operate if this board is not adequately mounted, so be sure to mount it securely. -
Page 9: Downloading Cricuit Data
CHAPTER 2: SETTING UP THE S5U1C88000P 2.2 Downloading Circuit Data This board (S5U1C88000P) comes with the FPGA that contains factory inspection data, therefore the circuit data for the model to be used should be downloaded. The following explains the downloading procedure. -
Page 10: Chapter 3 Product Specifications
CHAPTER 3: PRODUCT SPECIFICATIONS CHAPTER RODUCT PECIFICATIONS The specifications of the S5U1C88000P are listed below. S5U1C88000P 247.5 mm (wide) × 165 mm (depth) × 44.6 mm (height) Dimension: Weight: Approx. 500 g Power supply: DC 5 V ± 5%, less than 1 A (supplied from ICE main unit) - Page 11 Central Phone: +852-2585-4600 Fax: +852-2827-4346 101 Virginia Street, Suite 290 Telex: 65542 EPSCO HX Crystal Lake, IL 60014, U.S.A. EPSON TAIWAN TECHNOLOGY & TRADING LTD. Phone: +1-815-455-7630 Fax: +1-815-455-7633 10F, No. 287, Nanking East Road, Sec. 3 Northeast Taipei 301 Edgewater Place, Suite 120...
- Page 12 S5U1C88000P Manual (S1C88 Family Peripheral Circuit Board) ELECTRONIC DEVICES MARKETING DIVISION EPSON Electronic Devices Website http://www.epson.co.jp/device/ Issue May, 2001 Printed in Japan...
- Page 13 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Epson S5U1C88000P1200...
