5.3.3 Editor area

Error marker

This is the area of the editor where you edit source code. The IDE has an editor for C sources and an editor for as-

sembler sources. These editors have the same features as a general-purpose editor, and error messages or variable

or function names displayed in other views can be linked to the editor. Multiple documents can be opened at a time,

any of which can be selected with a tab at the top of the area in which its document name is displayed.

The marker bar on the left edge of the editor area shows the line in error and the markers indicating a bookmark, a

line in which a task is set, etc. Hover the mouse pointer over a marker to display the contents of an error, the name

of a bookmark, or a task explanation.

As for the marker bar, the overview ruler on the right edge of the area shows the position in error and the position at

which a bookmark or task is set by a square symbol. The positions displayed on this side do not correspond to the

current display position; they are relative positions seen from the entire file. Hover the mouse pointer over a symbol

to display explanations as for the marker. Click a symbol to go to that position.

In addition to the built-in editors, you can start an external editor from the IDE and edit the sources in it. For more

information on editing features, refer to Section 5.5, "The Editor and Editing of Source Files".

(C COMPilEr PaCkagE fOr S1C17 faMily) (Ver. 1.5.0)

Overview ruler

Editing area
