PRISM Media Analysis Platform User Manual
Table 4: Instrument settings that are reset by recalling the Factory preset (cont.)
Item
SDI-In 3 input configuration
Input name
Input type
Input connector
SDI-In 4 input configuration
Input name
Input type
Input connector
SDI-SFP+ 1 input configuration
Input name
Input type
Input connector
SDI-SFP+ 2 input configuration
Input name
Input type
Input connector
PTP reference configuration
PTP Logging to the Event Log
Selected Profile
ST2059 domain
ST2059 communication mode
How to configure the instrument
Setting
SDI-In 3
SDI
SDI 3
SDI-In 4
SDI
SDI 4
SDI-SFP+ 1
SDI
None selected
SDI-SFP+ 2
SDI
None selected
Enabled
ST2059
127
Multicast
65
