3D LUT conversion (Option
MP-PROD only)
Figure 36: Vector display with (right) and without (left) 3D LUT enabled, 100% color bar in PQ/BT.2020
PRISM Media Analysis Platform User Manual
3D LUT conversion is available in Waveform, Vector and Diamond display
applications. Use the Convert to Rec. 709 button to convert the Gamma / Gamut
settings for the signal to the BT. 709 Gamma / Gamut signal. This feature allows
you to match the skin tone and the color in BT. 709 Gamma / Gamut displays.
The conversion between input video and linear light is processed in Scene light.
How to configure the instrument
55
