Getting started

MPI power-on and power-off procedures

MPI power cord installation
12
2. For the MPI-RACK-MM cabinet only, repeat step 1 to install a second MPI
monitor in the right slot of the dual rack cabinet.
3. For the MPI-RACK-MW cabinet only:
a. Install a Tektronix WFM52x0, WFM7200, or WFM8x00 waveform
monitor in the right slot of the dual rack cabinet. (See Figure 1.) (See
Figure 2.)
b. Use two screws (item 3 in Table 2) to secure the waveform monitor in
the dual rack cabinet. The screws attach to the right and left holes in the
middle of the instrument chassis as viewed from the rear.
c. Connect power and signal cables to the waveform monitor as needed.
NOTE.
See the installation manual for your waveform monitor for information
about making power and signal connections to the instrument.
This section describes how to apply power to the MPI monitor and how to
power-on and power-off the instrument.
The MPI monitor is powered by the DC output of an AC power adapter. Connect
the AC adapter to the power connector on the rear panel of the instrument as
shown below. The power connector is keyed to be directional, with the flat portion
of the power cord housing facing the left of the instrument (as viewed from the
rear). When fully inserted, the power cord housing latches on the instrument
power connector.
CAUTION. To minimize the risk of damage to the instrument, it is strongly
recommended that the AC adapter be connected to the MPI monitor before the
adapter is connected to the AC power source.
