PRISM Media Analysis Platform User Manual
3. Enter the Source and Destination information for Path 1 and Path 2, if
applicable.
NOTE. You may have to scroll down to see Path 2.
4. To have the instrument ignore a parameter, touch the Unmasked control next
to the parameter to toggle the state to Masked.
5. To edit one of the parameter values, touch inside the parameter box to open
the editing display shown below.
Figure 30: Editing parameter fields
6. When you are done editing touch the Enter key.
7. Scroll down to enter the Source and Destination information for Path 2.
NOTE.
If ST2022-7 Seamless Switching is set to Disabled only Path 1 is available,
Path 2 will be grayed out.
8. Select Save and close the menu.
How to configure the instrument
49
