Methods of operation
MPX front panel operation
34
You can use the instrument front panel to perform the following functions:
Recall instrument presets
Select an input to monitor
Control or mute the volume on the headphone outputs
Connect a mouse and keyboard
Connect a USB drive to import or export instrument presets, upgrade the
instrument firmware, or save screen and stream captures
NOTE. It is strongly recommended you do NOT use the front USB 2.0 ports for
stream captures. Using a USB 2.0 port for stream captures will take an excessive
amount of time. Use the rear panel USB 3.0 ports for stream captures.
How to recall instrument presets (MPX). Perform the following steps to recall
instrument presets using the front panel:
1. Press the PRESET button once to prepare the instrument for a preset selection
from preset Group A using the SELECTIONS buttons (1-6).
2. Press the PRESET button repeatedly to select preset Group B-F. The selected
preset group will be displayed.
3. After you select the desired preset group, press the SELECTIONS numbered
button corresponding to the preset in that group you want to recall (1-6).
NOTE.
When you use the PRESET and INPUT buttons, the associated menus
appear on the display. The menus close after a short time-out period. Similarly,
when you use the VOLUME control, the volume slider and mute controls appear
on the display and close after a short time-out period.
How to select an input to monitor (MPX). Perform the following steps to recall
instrument presets using the front panel:
1. Press the INPUT button to prepare the instrument for an input selection.
2. Press the SELECTIONS numbered button corresponding to the input you
want to monitor.
