PRISM Media Analysis Platform User Manual
To rename a signal input.
1. To rename the input to a meaningful name, touch the Name box to open
the text editing display shown below.

Figure 28: Renaming a signal input

2. Use the editing controls to enter a new name for the input. Here are some
notes on using the text editor.
Enter a name with a maximum of 16 characters.
Use the icon next to the input box to clear the existing name.
Use the shift key to access capital letters.
Use the backspace key to delete characters by backspacing over them.
Use the 123 and abc keys to toggle between accessing letters and
numbers/symbols.
3. When you are done editing the input name, touch the Enter key.
4. When you are done editing the input, touch Save to save your changes.
How to configure the instrument
47
