Application information
90
When the Parade display style is active you can select from 1 line or 1 field.
When Overlay display style is active you can select from 1 line, 2 line, 1
field, or 2 field.
Display Mode. Use the drop-down menu to select from the following the choices
(only available while displaying SDI inputs) in the menu:
Y. Displays the input as Luma (Y) components.
RGB. Displays the input as Red (R), Green (G), and Blue (B) components.
YPbPr. Displays the input as Luma (Y) and color difference (Pb, Pr)
components.
YRGB. Displays the input as Luma (Y), Red (R), Green (G), and Blue (B)
components.
Graticule. Use the drop-down menu to change the vertical scale value to %, mV,
Code Value, Stop, Reflectance, or Nits.
NOTE. The Code Value vertical unit is a hex value. The Stop, Reflectance and Nits
scale are drawn differently depending on the Gamma setting in the input menu.
Convert to Rec. 709. Turn this setting On to allow the trace displays to convert
the Gamma and Color Gamut settings for the signal to SDR Narrow and BT. 709
(requires Option MP-PROD).
NOTE.
Convert to Rec. 709 automatically converts to BT.709, otherwise the
graticule selection must be manually changed (See page 53, How to configure the
instrument for HDR / WCG monitoring.)
Show Active Area Only. Use the button to turn Show Active Area Only On or Off.
When the option is On it removes the trace of vertical / horizontal blanking data.
