PRISM Media Analysis Platform User Manual
6. Touch the Domain (0-127) box to open the editing display shown below.

Figure 38: Editing the PTP domain setting

7. Use the editing controls to enter a new domain number. Here are some notes
on using the editor:
Use the icon to clear the existing domain number.
Use the backspace key to delete characters by backspacing over them.
8. When you are done editing the domain number, touch the Enter key.
9. Repeat steps 4 to 6 for each PTP profile.
How to configure the instrument
57
