Application information

Base instrument
applications
Option MP-IP-STD
application
PRISM Media Analysis Platform User Manual
This section describes each of the available applications on the PRISM monitor.
All applications can be viewed in four-tile mode and full-screen mode. Double
tap in an application to toggle between these two modes.
NOTE.
Some displays require a specific option to be installed. For example, the
IP Status display is not accessible unless you have Option MP-IP-STD.
The following applications are available on every PRISM monitor:
Waveform application. Use this application to view selections of YPbPr
Luma (Y) and Color Difference (PbPr) or YRGB Luma, Red, Green and
Blue. (See page 88, Waveform display application .)
Vector application. Use this application to calls up the Vector and Lightning
displays, which provide for selection between two plots of the color portions
of the signal. (See page 94, Vector application .)
Picture application. Use this application to view the picture generated by the
video signal. (See page 106, Picture application .)
Audio application. Use this application to view a level meters display of
the audio in the monitored signal using True Peak ballistics. Also included
are Test level and Peak program level indicators. (See page 107, Audio
application.)
Video Session application. Use this application to view various performance
parameters of the SDI video signal or the decoded IP stream. (See page 110,
Video Session application .)
Event Log application. Use this application to view a log of detected errors.
(See page 116, Event Log application .)
The following additional application is available when Option MP-IP-STD is
installed:
IP Status application. Use this application to see an overview of the
monitored IP stream and see the status of each program in the stream. (See
page 122, IP Status application .)
Application information
85
