Functions
84
6. Select Stream Size (MB) to set the size of the capture.
NOTE.
The minimum stream size is 1MB and the maximum size is 2000MB.

Figure 64: Stream Size settings

7. Select to close settings.
8. Select the Capture icon on the application bar to start the process. When the
capture type is Screenshot and Stream a percentage will be displayed under
the Capture icon.
Figure 65: Stream capture icon with percentage shown
NOTE.
Select the Capture icon again to stop the stream capture early. The
Capture icon is the only element you can interact with on the PRISM monitor
while the capture and save are taking place.
9. A screenshot and .pcap file are saved to an attached USB device. The monitor
will display the name of the file and the path to the file on the USB device
upon completion.
10. Select OK to close the dialog box.
