Getting started
MPI power cord removal
MPI power-on procedure
14
The power cord housing latches on the instrument power connector when fully
inserted. To remove the power cord, grasp the connector housing as shown below
and firmly pull the cord away from the instrument.
CAUTION.
To prevent damage to the power cord or to the instrument power
connector, do not attempt to disconnect the power cord by pulling on the cable.
You must pull on the connector housing to disengage the locking mechanism.
To minimize the risk of damage to the instrument, it is strongly recommended that
the AC adapter be disconnected from the AC power source before the adapter
is disconnected from the instrument.

Figure 6: Disconnecting the power cord from the MPI monitor

1. Apply power to the instrument. (See page 12, MPI power cord installation.)
NOTE.
If the MPI monitor was previously powered off by a power interruption
or by removing the power cord from the rear of the instrument, the instrument
will power on when power is reapplied.
2. Press the Power/Standby button on the instrument front panel to turn the
instrument on.
NOTE. The Power/Standby button illuminates during the power-on sequence and
then turns off during normal instrument operation.
