Elements of the Event Log
application display

Figure 97: Event application Go to Bottom icon

Figure 98: Event application slider control
PRISM Media Analysis Platform User Manual
Reset icon. Use the
all log items, so only new log items will be displayed. Press and hold the icon
for ten seconds to display the log items that were previou sly hidden.
Go to Bottom icon. Use the
displayed Event Log buffer where you can monitor any new events. The most
recent events are at the bottom of the event list.
Slider control. When the Event Log contains more than 1,000 entries, you
can touch the top of the application display to activate a down arrow as shown
above. Touch and swipe down near the arrow to open a slider control which
allows you to quickly navigate through the Event Log entries. Use the slider
control for approximate positioning within the Event Log, and then swipe
up or down to fine tune the position.
Alternately, you can use the slider control to the right of the screen to swipe
up or down through the event log.
The readout to the left of the slider control shows the date and time, according
to the internal clock, of the current position in the Event Log. The date is
displayed as YYYY-MM-DD and the time is displayed as HH:MM:SS. Use
the slider to reposition the Event Log display buffer to a different location in
the log, where a new set of 100 events will be displayed.
When the slider control is displayed, touch and swipe the up arrow at the
bottom of the slider to close the control.
icon to hide old log items. Press the icon once to hide
icon to go to the end of the currently
Application information
117
