How to configure the instrument
44
3. Use the UHD/4K Mode drop-down menu to select Auto, Sq Div (Square
Division) or 2 SI (Two Sample Interleave).
NOTE.
In AUTO mode, the instrument defaults to Two Sample Interleave mode
if the Video Payload Identifier (VPID) complies with SMPTE 425.3 or SMPTE
425.5. The instrument defaults to Square Division mode if the VPID complies with
SMPTE 292.1, SMPTE 372, SMPTE 425.1, or a quad-HD signal is present and
VPID is missing. VPID in the signal is required for this option to operate properly.
4. Select Save and close the menu.
PRISM Media Analysis Platform User Manual
