Application information

Vector application

Figure 72: Vector application display
Vector application banner
94
The Vector application equipped with a 3D LUT conversion allows operators to
match skin tones of video signals to standard BT.709 vector locations and to
verify wide color gamut compatibility to BT.709 color gamut.
The following figure shows the available options after pressing and holding
anywhere on the Vector application tile.
Figure 73: Vector application banner
The following options adjust how the Vector application is displayed:
The maximize icon ( ) expands the Vector application tile to the full screen.
The minimize icon ( ) collapse the tile back to its original size.
