Getting started
6
Supplied hardware. The following table lists the hardware supplied with the dual
rack cabinet kit. The installation instructions includes references to these parts by
the item numbers to aid in selecting the correct parts.

Table 2: Supplied hardware

Item Tektronix part
number number
1 210-1061-00
2 210-1298-01
3 211-0511-00
4 211-0718-00
5 212-0577-00
6 212-0591-00
7 381-0251-01
8 407-3752-00
9 407-6011-00
Description
WASHER, FLAT; 0.203 ID X 0.625 OD X
0.062, ZINC PLATED STEEL
WASHER; SHOULDER & RETAINER,
0.195 ID X 0.195 THK, PLASTIC, TV GRAY,
6.575 OD
SCREW, MACHINE; 6-32 X 0.5, PNH,
STEEL, ZINC PLATED, T15 TORX
SCREW, MACHINE; 6-32 X 0.312, FLH100,
STEEL, ZINC FINISH, T-10 TORX DR
SCREW, MACHINE; 10-32 X 0.625, TRH,
ZINC PLATED STEEL, PHIL
SCREW, MACHINE; 10-32X.750 OVAL
HEAD, POZI
NUT BAR; 10-32 X 3.0 X 0.375 X 0.120
BRACKET, EXT; 2.5 X 8.06 X 0.06, STEEL;
SAFETY CONTROLLED
RACK MOUNT, INSTRUMENT MTG
BRACKET, 5000 SERIES
PRISM Media Analysis Platform User Manual
Quantity
4
4
8
4
8
4
4
2
1
