Application information
Option MP-IP-MEAS
applications
Option PHY-12G
applications
Option MP-PROD
applications and settings
86
The following additional applications are available when Option MP-IP-MEAS is
installed (requires Option MP-IP-STD):
IP Session application. Use this application to view various performance
parameters of the IP stream including Layer 2, video and PTP parameters.
(See page 126, IP Session application .)
IP Graphs application. Use this application to view trend graphs of various
performance parameters of the IP stream including total bit rate, session bit
rate, PIT, RTP sequence errors, video CRC errors, and TS-DF (Time Stamped
Delay Factor). (See page 138, IP Graphs application.)
PIT Histogram application. Use this application to view a histogram of the
PIT (Packet Interval Time) to monitor network delay variation statistics. (See
page 144, PIT Histogram application.)
Timing application. Use this application to view timing offsets between the
incoming video and PTP signals. (See page 119, Timing application.)
PTP Graphs application. Use this application to view trend graphs of
various performance parameters of the PTP signal include Master-to-Slave
and Slave-to-Master delays and variances. (See page 146, PTP graphs
application.)
The following additional applications are available when Option PHY-12G is
installed (Software option MP-FMT-4K required for 12G support):
Eye Display application. Use this application to view an eye pattern diagram
of the SDI input only. (See page 100, Eye Display application .)
Jitter Display application. Use this application to display the wave shape of
the jitter and allows you to view additional time-domain information. (See
page 103, Jitter Display application .)
The following additional applications are available when Option MP-PROD is
installed:
Stop Display application. Use this application to monitor video signals with
a variety of transfer functions in a consistent manner. (See page 91, Stop
Display application .)
Diamond application. Use this application to reliably detect invalid colors.
(See page 96, Diamond display application .)
Convert to Rec. 709. Use this setting to allow the trace displays to convert
camera logs to Rec. 709.
