Application information
Figure 112: IP Graphs application display
Total Bit Rate graph
140
The Total Bit Rate graph shows the total bit rate currently on the 10 GbE input.
The maximum available bandwidth is 10.3 Gb/s.
The following readouts appear:
Max: Shows maximum bandwidth used during the time window.
Mean: Shows the mean bandwidth used during the time window.
Min: Shows the minimum bandwidth used during the time window.
Free Min/Max: Shows the minimum and maximum available bandwidth
that is not being consumed.
PRISM Media Analysis Platform User Manual
